Nest of Tables
Assembly Instructions
Dimensions
Large / Small
Width - 56/40cm
Depth - 40/30cm
Height - 47/35.5cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
- Please keep for future reference
609/1439
609/1893
609/3688
609/6300
Version 2
Date: 03/10/11
Advertisement
Related Manuals for Argos Nest of Tables 609/1439
Summary of Contents for Argos Nest of Tables 609/1439
- Page 1 Nest of Tables 609/1439 Assembly Instructions - Please keep for future reference 609/1893 609/3688 609/6300 Dimensions Large / Small Width - 56/40cm Depth - 40/30cm Height - 47/35.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Version 2 Date: 03/10/11...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand on the product, • We do not components and tools listed on this could cause damage. recommend the pages 2 and 3. - Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Pilot holes for guidance only Large support x 2 (43.8 x 6cm) Pilot holes for guidance only Pilot holes for guidance only Medium support x 4...
- Page 4 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. in some cases mor may be supplied than are required. Dowel x 24 Locking pin x 16 14mm Screw x 20 Glue x 1 15mm Locking nut x 16 Plastic support x 10 Tools required Small...
- Page 5 Assembly Instructions Step 1 Fitting the legs Note: It would be useful to ask someone to help you at this stage. Place a small amount of Glue into the dowel holes. Insert Dowels into the Large and Medium , Small supports Screw in Locking pins into the Large and Small legs...
- Page 6 Assembly Instructions Step 1 - continued Locking nuts Large legs the Medium support Use a screwdriver to turn Locking nuts clockwise to lock. Note: For small table, replace with Small legs , replace with Small supports Note: The screw holes on the medium supports or small supports should face inward.
- Page 7 Assembly Instructions Step 2 - continued Carefully locate the Large table top onto the unit. Note: For small table, replace with Small table top Plastic supports onto the Large table top and unit. Note: For small table, replace with Small table top...
- Page 8 Assembly Instructions Step 3 Finishing the unit Note: It would be useful to ask someone to help you at this stage. Carefully turn the table Large table upright. Note: Before use allow the Glue to dry for 24 hours and make sure the unit is secure.
