Page 2: Table Of Contents
Thank you for your purchase of this product. Before operating the product, please read this instruction manual carefully to ensure proper use of the product. Please store this instruction manual in a safe place for future reference. CONTENTS PRODUCT FEATURES ... EG-2 SAFETY PRECAUTIONS ... -
Page 3: Parts Description
PARTS DESCRIPTION 1. ZC-BT series Outside Bracket Inside Service connector (*optional) * Unscrew the Front Cover counterclockwise to open the unit for adjustments. Once adjusted, screw the Front Cover back and tighten it clockwise, and refrain from opening and closing frequently to ensure the best waterproof and condensation free performance. - Page 4 2. ZC-BX series Outside Bracket 2 3 5 6 Rear ● ZC-BX housing is designed to be adjusted externally. ALC ELC adjustment and BLC ON/OFF can be made only by Magnetic Control Bolt (MCB). Once Front Cover is unlocked for any reason, its outdoor performance cannot be guaranteed.
-
Page 5: Installation And Adjustment
INSTALLATION AND ADJUSTMENT Attaching to the ceiling Attaching to the wall Attaching to the ceiling or wall This section explains how to install the unit where cables are running through the interior of the ceiling or wall. - Drilling holes in the ceiling or wall: Use the template included to mark out the position on the ceiling or wall where you want to install the unit. -
Page 6: Adjusting The Camera Direction
Adjusting the camera direction This camera can be easily adjusted for viewing in all directions. After attaching the camera on the wall or ceiling, adjust camera for the desired direction. Then tighten each locking ring and lock rings with an allen wrench as shown in the picture below. - Page 7 Adjusting the DIP Switch Mode (for ZC-BT series only) ● DIP Switch is available for ZC-BT series only and each of the following functions can be adjusted by ON/OFF of the Switch. The setting modes shown at left are (= ) actual factory default settings. ELC/ALC ELC Easy back focus adjustment to maximize the best focusing (refer to Attention...
- Page 8 ELC/ALC ELC Easy back focus adjustment to maximize the best focusing (refer to Attention below) *ON/OFF adjustable ALC Factory set position by MCB BLC (Back Light Compensation) *ON/OFF adjustable OFF Factory set position by MCB ● ELC Mode: This mode helps make the focus adjustment easier in the fi eld of installation. Simply make the adjustment in the following order: - Select ELC mode - Adjust lens focus well...
-
Page 9: Specifications
Operation: Max. 85%RH / Storage: Max. 95%RH IP66 117(L) x 84Ф (Included sunshield) DC Iris Adjustment Dip Switch Wrench, Bracket Tapping Screw (M4x20 : 3pcs), Template, Instruction Manual, Additional Power Connector EG-9 ZC-BX4312NHA ZC-BNX4312NHA NTSC Digital Mechanical Day / Night Day / Night 0.45 5.5W... - Page 10 LENS SPECIFICATIONS Max. aperture ratio Focal length Iris (DC auto iris) Angle of view (Wide to Tele) * The specifi cations and/or appearance of the product may change without a prior notice. 1:1.4 - 2.9 3.3mm - 12mm F1.4 - F360C 125.70°...
- Page 11 122-2.0...
