Dometic SeaLand 4300 Series Owner's Manual

Gravity discharge toilet
Hide thumbs
Table of Contents

Advertisement

Quick Links

SeaLand
®
Gravity diScharGe toiLet
owner'S ManuaL
SeaLand
4300, 4400 Series
®
all-ceramic toilets
4400 Series
4300 Series
(with remote flush switch)
(with flush handle)
!
WARNING
this manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can result
in property damage.
dometic Sanitation corporation
328 State Rt 226, PO Box 38
Big Prairie, OH 446
SeaLand Product Customer Service: -800-32-9886
www.DometicUSA.com


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SeaLand 4300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dometic SeaLand 4300 Series

Summary of Contents for Dometic SeaLand 4300 Series

  • Page 1 Modification of this product can result in property damage. dometic Sanitation corporation 328 State Rt 226, PO Box 38 Big Prairie, OH 446 SeaLand Product Customer Service: -800-32-9886 www.DometicUSA.com...

  • Page 2: Table Of Contents

    ORdeRING PARtS Dometic is ready to assist you in the event service is required. Before calling, please have the following information available. Your cooperation in having this information ready is appreciated and allows us to better meet your needs.

  • Page 3: Toilet Dimensions

    toiLet diMenSionS Dimensions may vary ±3/8-inch (13mm). inStaLLation inStructionS System requirements: • 4 GPM (5 lpm) or larger water pump. • 1/2-inch (12.7 mm) water line terminating in 1/2-inch MPT fitting (to connect to toilet water supply hose). • 4-bolt floor (closet) flange. SeaLand flanges available include 3-inch spigot, socket, MPT, or 45-degree swivel socket.
  • Page 4 STEP 5a: For through-the-floor water line and electrical wires, mark another centerline 6 inches (52 mm) from below-floor installation the back wall (fig. 4). fig. 4 STEP 5b: For through-the-wall water line and electrical above-floor installation wires, mark a centerline 8 inches (203 mm) up from the floor centerline (fig.
  • Page 5 iMPortant: if replacing an existing toilet that uses for ModeL 4400 toiLet a 2-bolt floor flange, drill two 5/16-inch dia. holes in old floor flange that align with two additional holes WItH ReMOte SWItCH in floor flange adapter. use two #10 or 12 x 1-1/2-inch oPeration, see page 7 wood screws and washers for these drilled holes, for wall switch installation...
  • Page 6 STEP 16: With toilet close to floor flange, connect flex- STEP 19: Set the toilet in place (fig. 19) and secure to ible water supply hose to the water line fitting (fig. 17). floor with the #14x2-1/2 inch long lag bolts (fig. 20). Install decorative bolt caps by pushing them onto bolt heads (fig.

  • Page 7: Remote Flush Switch Installation

    ModeL 4400 reMote fLuSh Switch inStaLLation 4400 series toilets feature a remote flush switch to control the “flush” and “add water” functions. follow the instructions below for switch installation. STEP : Select a location for the switch. 8 feet of cable (2.4 m) is provided.

  • Page 8: Important Information Before Operation

    iMPortant inforMation before oPeration . Fill freshwater tank and add deodorant to holding tank through toilet bowl. 2. Make sure all guests understand the operation of the toilet system. 4300 models: Follow instructions below. 4400 models: "Add Water" and "Flush" are clearly marked on the remote switch. See more information below.

  • Page 9: Operating Instructions

    eLectronic toiLet oPeration (cont'd) 1. adding More water to toilet bowl Pull up the flush handle (4300 model) or push "Add Water" switch (4400 model) until the desired water level is attained. 2. flushing the toilet Push the flush handle down (4300 model) or push "Flush" switch (4400 model) for a moment, then release it. ManuaL override In the event of a power failure, you can use the "Manual Override Lever"...

  • Page 10: Spare Parts

    Dometic manufactures both types of deodorants. Generally speak- ing, formaldehyde formulas control odor very effectively at all temperatures and with all degrees of water hardness.

  • Page 11: Base Assembly Components

    baSe aSSeMbLy coMPonentS 3. Lift china toilet . To access base straight up from base assembly components, and set it down just in remove decorative screw front of floor flange. caps and unscrew two bolts that hold china toilet Turn off water to to floor.

  • Page 12: Wiring Diagram

    eLectricaL SPecificationS 12vdc Maximum operating current (amps): Flush motor locked rotor current (amps): Maximum voltage: 4.5 Minimum voltage: Input power wire size 4 ga. All other wires size: 8 ga. Fuse size (amps) WIRING dIAGRAM 4300 and 4400 SerieS toiLetS...

  • Page 13: Troubleshooting

    troubLeShootinG SyMPtoM 1. toilet will not flush and water will not enter toilet bowl. Condition Possible Causes Fuse blown or circuit breaker • Check toilet fuse or circuit breaker at DC distribution panel. is tripped: • Check for loose or defective wiring between power source and toilet terminal block pins 5 and 8.
  • Page 14 troubLeShootinG (cont’d) SyMPtoM 6. flush ball constantly cycles between open and closed position. Condition Possible Causes Component adjustment required or • Cam switch needs adjustment. See adjustment procedure for flush defective component: ball over-travel on page 6. • Cam switch is defective. See replacement instructions on page 7. •...
  • Page 15 troubLeShootinG (cont’d) SyMPtoM 12. water will not stay in bowl (leaks down through flush ball seal). Condition Possible Causes Incomplete seal between • Cam switch needs adjustment (see adjustment procedure for flush flush ball and Teflon seal: ball over-travel, page 6). ®...
  • Page 16 troubLeShootinG (cont’d) adJuStinG caM Switch/ fLuSh baLL aLiGnMent The flush ball is properly positioned so that the “A” and “B” distances are equal (see FLUSH illustration at right). If the flush ball becomes BALL misaligned (resulting in water leaking from bowl or other flushing problems), follow instructions below to resolve problem.
  • Page 17 troubLeShootinG (cont’d) rePLacinG the fLuSh baLL SeaL 2. Remember to keep the rotor shaft in the closed position when installing the new flush valve. and bowL SeaL 3. The cam switch will require readjustment after . Turn off water and electrical power to toilet. flush ball installation.

  • Page 18: Customer Service

    Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET) parts needs. They carry a complete inventory for the SeaLand Monday through Friday. You may also write us at Dometic product line. Corp., P.O. Box 38, Big Prairie Ohio 446.
  • Page 19 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 20: Warranty

    If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.

This manual is also suitable for:

Sealand 4400 series
