  • Page 1 Macerator Toilet Installation Elektrische Toilette Installation . . . . . . . . . . . . . . . . . . . . 13 WC dilacérateur Installation .
  • Page 2 SeaLand MasterFlush Toilet...

  • Page 3: Table Of Contents

    Modification of this product may result in property damage. Dometic recommends that a qualified marine technician or electrician install or service this product . Equipment damage, injury to personnel or death could result from improper installation . DOMETIC...

  • Page 4: General Safety Instructions

    . To prevent this pos- sibility, Dometic recommends using the “full” tank shut-down relay in the toilet’s electronic control module . The “full” signal from the holding tank can be generated by an optional...

  • Page 5: Components

    Macerator toilet Dometic DFT flush switch Control module 4-wire cable to toilet macerator pump and water valve Dometic DFT touchpad, DFS or DFP flush switch cable 8900 series – all models Cable for previous flush switch connections (discontinued models) Incoming electrical power wires Power wires to raw water pump (opt .)

  • Page 6: Specifications

    Specifications SeaLand MasterFlush Toilet Specifications Materials Toilet: vitreous ceramic Dometic DFT switch panel frame: ABS Dometic DFT switch panel: polycarbonate resin Macerator pump body: glass-filled polypropylene Control module housing: ABS Minimum System Requirements Circuit breaker 20 amps/12 V DC; 15 amps/24 V DC...
  • Page 7 15 .375 in . / 391 mm 33 .5 in . / 851 mm - seat lid up 30 .5 in . / 775 mm - seat lid up Dometic flush switch/status panel Control module (fig . , page 2) (fig .

  • Page 8: Installation

    Installation SeaLand MasterFlush Toilet Installation Fresh water system layout SeaLand macerator toilets can operate with an anywhere in the piping system is opened . onboard pressurized freshwater system with a SeaLand toilets are equipped with an electrically minimum flow rate of 2 .0 gpm (7 .6 lpm) at the operated water valve and an in-line check valve toilet .
  • Page 9 . Instructions for these are included with each flush switch assembly . 6 . Use Dometic DFT touchpad template to mark location of fastener and access holes . Drill 1 in . (25 mm) hole, then fasten panel bracket to wall (fig .
  • Page 10 Installation SeaLand MasterFlush Toilet 11 . Route water supply and discharge plumbing to toilet according to system requirements (Section 4.2) . Make sure to provide extra discharge hose length to assure easy connection to toilet (fig . 12 . Loosen band clamp on discharge loop outlet and remove discharge adapter fitting/hose fitting assembly (fig .
  • Page 11 SeaLand MasterFlush Toilet Installation Toilet system with through-the-wall connections 1 . To route wiring and plumbing connections through the wall, use floor template to locate the vertical centerline of each hole . 2 . Place toilet in proper position and mark horizontal centerlines (fig .

  • Page 12: Customer Service

    . Dometic Group supplies a wide range of workshop equipment for service and maintenance of built-in air conditioners . Dometic Group also provides specially...
