ECOVAC
™
VACUUM TOILET SYSTEM
OWNER'S MANUAL
!
WARNING
This manual must be read and understood
before adjustment, service, or maintenance is
performed. Modification of this product can
result in property damage.
Dometic Corporation • Sanitation Systems
13128 State Rt. 226, P.O. Box 38
Big Prairie, OH 44611-0038 USA
SeaLand Product Hotline 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
1

Advertisement

Table of Contents
loading

Related Manuals for Dometic Sealand ECOVAC

Summary of Contents for Dometic Sealand ECOVAC

  • Page 1 This manual must be read and understood before adjustment, service, or maintenance is performed. Modification of this product can result in property damage. Dometic Corporation • Sanitation Systems 13128 State Rt. 226, P.O. Box 38 Big Prairie, OH 44611-0038 USA SeaLand Product Hotline 1-800-321-9886...

  • Page 2: Table Of Contents

    WARNING – PUMP STARTS AUTOMATICALLY. Turn off electrical power before servicing. Turn off electrical power before servicing. PRODUCT FEATURES Dometic brings the technology, comfort and efficiency of EcoVac™ toilet systems in an easy-to-use and easy-to-maintain package. • Freshwater Flush •...

  • Page 3: Key System Components

    KEY SYSTEM COMPONENTS VACUUM HOLDING TANK SYSTEM Vacuum Toilet: The EcoVac™ toilet operates in a way different from other marine toilets. EcoVac sys- tems use a small amount of water (a little more than a pint) per flush in addition to a simple vacuum. The toilet is connected to a pressurized freshwater system.

  • Page 4: Toilet Model Identification

    TOILET MODEL IDENTIFICATION The toilet model identifi cation label is located on the toilet base and will show DOMETIC CORPORATION the model number and serial number. P.O. BOX 38, 13128 STATE RT 226 (800) 321-9886 BIG PRAIRIE, OH 44611 USA MODEL NO.

  • Page 5: Proper Cleaning

    PROPER CLEANING – TOILET BOWL AND SEAL The EcoVac toilet should be cleaned regularly for maximum sanitation and operational efficiency. Clean it just as you would a household toilet. Fig. A Do not use caustic chemicals, such as drain-opening types, as they will damage the seals.

  • Page 6: Maintenance

    *See Base Assembly - Page 8. VACUUM TESTER Dometic has developed a simple tool to assist in identifying the location of vacuum leaks. The vacuum tester consists of a vacuum gauge and a cone-shaped plug. Inserting the plug in the inlet of the vacuum tank or generator isolates the toilet from the system.

  • Page 7: Convenience Products

    379441204 ORDERING PARTS Dometic is ready to assist you in the event service is required. Before calling, please have the following infor- mation available. Your cooperation in having this information ready is appreciated and allows our Customer Service Department to better meet your needs. When you call, we will direct you to the nearest stocking parts distributor.

  • Page 8: Troubleshooting Guide

    TROUBLESHOOTING GUIDE ADJUSTING NUT BALL SEAL BASE ASSEMBLY REAR VIEW, VACUUM TOILET FLUSH BALL VACUUM FLUSH PEDAL BREAKER WATER VALVE ASSEMBLY CLAMP RING HOSE CONNECTION TOP VALVE CAP VALVE SEAT FILTER SCREEN SPRING CARTRIDGE SHAFT VALVE BODY WATER VALVE VACUUM BREAKER/BOWL CONNECTION SCREWS PEDAL COVER...
  • Page 9 TROUBLESHOOTING GUIDE (cont’d) Problem Possible Cause Service Instructions a. Worn or defective vacuum breaker. a. Remove vacuum breaker cover and 7. Water leaking from rear of look into top of vacuum breaker. toilet bowl. Flush toilet. If water leaks during flush, vacuum breaker needs to be replaced.
  • Page 10 TROUBLESHOOTING GUIDE (cont’d) Problem Possible Cause Service Instructions a. There is a blockage in the system. a. Open flush ball and check the 1-inch 13. Toilet will not flush. (25mm) orifice at the bottom of the (No vacuum.) base for blockage and dislodge it. See problems 3 and 14 Never use drain-opening or other if necessary.

  • Page 11: Customer Service

    Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET) to your replacement parts needs. They carry a complete Monday through Friday. You may also write us at Dometic inventory for the SeaLand product line. Corp., P.O. Box 38, Big Prairie Ohio 44611.

  • Page 12: One-Year Limited Warranty

    If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
