Grizzly T1250 Quick Start Manual

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
The following change was recently made since the owner's manual was printed:
• Workbench now comes with (8) hex bolts and a wrench to attach end frames, center frame, and upper
supports to workbench top. There will be (8) M8-1.25 x 55 button head cap screws not used during
Assembly.
Aside from this information, all other content in the owner's manual applies and MUST be read and under-
stood for your own safety. IMPORTANT: Keep this update with the owner's manual for future reference.
For questions or help, contact our Tech Support at (570) 546-9663 or techsupport@grizzly.com.
Revised Inventory List
Additional Items (Figure 1)
I.
Hex Bolts ⁄ "-18 x 2" ................................. 8
5
16
J.
Open-End Wrench 12mm ........................... 1
I
Figure 1. Additional inventory items.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
READ THIS FIRST
Qty
J
COPYRIGHT © JANUARY, 2022 BY GRIZZLY INDUSTRIAL, INC.
#CS22213 PRINTED IN CHINA
Model T1250
***IMPORTANT UPDATE***
For Machines Mfd. Since 12/21
and Owner's Manual Printed 11/17
Revised Parts
9V2
9V2
9V2
9V2
16
REF PART # DESCRIPTION
1V2 PT1250001V2 WORKBENCH TOP 25 X 96 X 1-3/4 V2.12.21
9V2 PT1250009V2 HEX BOLT 5/16-18 X 2 V2.12.21
16 PT1250016 WRENCH 12MM OPEN-END
1V2
9V2
9V2
9V2
9V2
