Grizzly T10115 Instructions

Damage to your eyes, and lungs could
result from using this item without proper
protective gear, such as safety glasses and
a respirator.

Specifications

• Overall Size ................................. 18½" x 26"
• Table Size . ................................... 18½" x 22"
• Dust Port Size ........................................ 2½"
• Table Surface Height . .............................. 7½

Connection

Connect your benchtop downdraft table to your
dust collection system or Shop•Vac with a 2½"
dust hose and hose clamp.

Operation

To use the downdraft table, start your dust collec-
tor and sand your workpiece on the table.
For workpieces that are larger than the downdraft
table, the side and rear dust shields can be low-
ered to create additional clearance. Loosen the
necessary lock knobs (Figure 1), then lower the
appropriate dust shield.
COPyrigHT © NOVeMBer, 2008 By grizzLy iNDuSTriaL, iNC. reViSeD auguST, 2011 (ST)
WARNINg: NO PORTION OF THIS MANUAL MAy BE REPRODUCED IN ANy SHAPE
OR FORM WITHOUT THE WRITTEN APPROvAL OF gRIzzLy INDUSTRIAL, INC.
DOWNDRAFT TABLE
Dust Shield
Table Section

Cleaning

your table surface may be cleaned with a damp
rag. if your table surface gets gummy from wood
pitch, you can use a non-corrosive blade cleaner
to easily remove it without harming the tabletop
surface. DO NOT clean with products such as
brake parts cleaner, acetone, or gasoline that will
harm the paint on the table surface.
To remove sawdust that may become trapped
beneath the table, lift up on the table sections
to remove them, then vacuum the inside of the
table.
If you need help with your new item, call our Tech
Support at: (570) 546-9663.
#JB11329 PriNTeD iN TaiWaN
MODEL T10115
BENCHTOP
INSTRUCTIONS
Figure 1 Model T10115 identification.
.
Lock Knob
Carrying Handle
