Keypad: Description of the keys

Name
Backward
Home
Forward
Units
Start
Stop
Up arrow
Left arrow
Zero & Tare
Right arrow
Down Arrow
Cancel or Esc
Accept
Power
Information
Backlight
User Manual M2001/M2001X Smart Manometer with Rotary Gas Meter Test
www.calcert.com
15
10 20
5 25
0 30
Key Description
• It cycles backward through menu
options.
• Home key returns you to the
Measurement and Units
• Home key is disabled during tests and
edits
• It cycles forward through menu
options.
• Select a measurement unit.
• Start key begins a test or data log.
• Stop or Hold (Freeze) key.
• It increases digits by one.
• It switches between the P1 and P2
sensors displays.
• It moves the blinking cursor one space
at a time to the left.
• Zero key resets pressure values to
zero.
• It resets min max values.
• It sets edit values to zero.
• It resets relief valve test.
• As a Tare key, it turns off or turns on
the Tare function.
• It moves the blinking cursor one space
at a time to the right.
• It decreases digits by one.
• It switches between the P1 and P2
sensors displays.
• Cancel any editing or changes without
saving.
• It also stops tests.
Accept
• applies all editing and
changes, and then saves them.
• It also stops tests.
• Turns the Smart Manometer on or off.
• Displays information about the Smart
Manometer, internal sensor, attached
MTS sensor, and the firmware.
• It provides three levels of brightness
and off.
