Sample label for Intrinsically Safe Tethered
Sensors
Intrinsically Safe—MTSX Marking
See the figure of a sample label below.
Intrinsically Safe tethered sensors
MTSX Meriam Tethered Sensors
Directives for the proper use of equipment are located on
9R699-Intrinsically Safe Control Drawing
MTSX shipped.
Component substitution may impair Intrinsic Safety.
•
Repairs must be made at Meriam to retain the Intrinsic Safety
•
Certification.
Service sensors only in a safe location.
•
User Manual M2001/M2001X Smart Manometer with Rotary Gas Meter Test
www.calcert.com
15
10 20
5 25
0 30
that accompanies each
