- Page 1 User Guide User Guide C9200-4L(NA) 4G IoT Wireless Gateway Guangzhou Robustel LTD www.robustel.com...
- Page 2 The contents of this document are subject to change without notice due to continued progress in methodology, design and manufacturing. Robustel shall have no liability for any error or damage of any kind resulting from the use of this document.
- Page 3 Robustel accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the gateway, or for failure of the gateway to transmit or receive such data.
- Page 4 Robustel C9200 User Guide Protecting Your 4G IoT Wireless Gateway To ensure error-free usage, please install and operate your 4G IoT Wireless Gateway with care. Do remember the following: Do not expose the 4G IoT Wireless Gateway to extreme conditions such as high humidity / rain, high ...
- Page 5 People's Republic of China, and can also be used for reference in the logistics process of electronic and electrical products. The orange logo below is used for Robustel products: Indicates its warning attribute, that is, some hazardous substances are contained in the product.
- Page 6 Robustel C9200 User Guide Table 3: Toxic or Hazardous Substances or Elements with Defined Concentration Limits Name of the Part Hazardous Substances (Pb) (Hg) (Cd) (Cr (VI) ) (PBB) (PBDE) Metal parts Circuit modules Cables and cable assemblies Plastic and polymeric parts Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in SJ/T11363-2006.
- Page 7 Robustel C9200 User Guide Document History Updates between document versions are cumulative. Therefore, the latest document version contains all updates made to previous versions. Date Doc Version Change Description 5 Nov, 2018 v.1.0.0 Initial release 27 Nov, 2018 v.1.0.1 Added the FCC Statement RT_UG_C9200_v.1.0.1 for NA...
-
Page 8: Table Of Contents
Robustel C9200 User Guide Contents Chapter 1 Product Concept ........................... 9 1.1 Key Features ............................9 1.2 Package Contents........................... 10 1.3 Specifications ............................11 1.4 Dimensions............................13 1.5 Ordering Information ..........................14 Chapter 2 Hardware Installation ......................... 15 2.1 Front Panel Interface ..........................15 2.2 LED Indicators ............................ -
Page 9: Chapter 1 Product Concept
After years of continuous efforts, Robustel has become a pioneer in the Internet of Things industry. The 4G IoT Wireless Gateway (C9200-4L) customized for OTIS on the basis of ARM9 core by Robustel is a rugged hardware product offering state-of-the-art mobile connectivity for internet of things applications. C9200-4L is a powerful platform developed based on RobustOS, a Robustel self-developed and Linux-based operating system. -
Page 10: Package Contents
Before installing your C9200 Gateway, verify the kit contents as following. Note: The following pictures are for illustration purposes only, not based on their actual sizes. 1 x Robustel C9200-4L 4G IoT Wireless Gateway 1 x power adapter (12V DC, 1.5 A) ... -
Page 11: Specifications
LTE 4G antenna (SMA-J antenna) Stubby antenna sucker antenna Note: If any of the above items is missing or damaged, please contact your Robustel sales representative. 1.3 Specifications Kernel CPU: ARM926EJ-S core, main frequency 300MHz Memory: 64MB DDR2 ... - Page 12 Robustel C9200 User Guide Storage: 64MB FLASH Cellular Interface Number of antennas: 2 Connector: Standard SMA-K SIM：1（3.0V/1.8V） Band: LTE FDD: B2/ B4/ B12 WCDMA: B2/ B4/ B5 Bluetooth interface Number of antennas: 1 Connector: Standard RP-SMA-K ...
-
Page 13: Dimensions
Robustel C9200 User Guide Power Supply and Consumption Power supply interface: 3-position 5.08mm terminal Input voltage:9-36 VDC Power consumption: 60-80ma @ 12V in idle state Communication status 210ma (peak) @ 12V Physical Characteristics Housing: PC + ABS environmental protection plastic ... -
Page 14: Ordering Information
LTE FDD: B2/ B4/ B12 WCDMA : B2/ B4/ B5 Operating Environment -25 to +70 °C Relative Humidity 5 to 95% RH Note: For more Frequency information, please contact your Robustel sales representative. RT_UG_C9200_v.1.0.1 for NA 27 Nov. 2019 14/27... -
Page 15: Chapter 2 Hardware Installation
Robustel C9200 User Guide Chapter 2 Hardware Installation 2.1 Front Panel Interface Item Name Mark Functions Direction C9200 Gateway Power interface Power input positive, 9-36VDC CAN interface switch Control CAN port function switch C9200 Gateway CAN TERM (reserved) -
Page 16: Insert Or Remove Sim Card
Robustel C9200 User Guide Name Color Status Description Green On, fast blinking(250ms) Gateway is powered on On, slow blinking(500ms) Gateway starts operating Gateway is powered off Green On, solid Link connection is working On, blinking In link communication Link is disconnected... -
Page 17: Attach External Antenna (Sma Type)
Robustel C9200 User Guide Note: 1. Use the specific M2M SIM card when the device is working in extreme temperature, because the regular card for long-time working in harsh environment will be disconnected frequently. 2. Do not touch the metal of the card surface in case information in the card will lose or be destroyed. -
Page 18: Mount The 4G Iot Wireless Gateway
Robustel C9200 User Guide 2.5 Mount the 4G IoT Wireless Gateway The 4G IoT Wireless gateway can be can be placed on a desktop or magnet installation. Magnet installation method 2.6 Connect the 4G IoT Wireless Gateway to a Computer Use a microUSB data cable to connect the microUSB interface of 4G IoT Wireless Gateway to the USB interface of the computer. -
Page 19: Power Supply
Robustel C9200 User Guide 2.7 Power Supply COLOR POLARITY YELLOW Connect the power adapter to the gateway power interface as shown in the figure above. Note: there are positive and negative wires on the power adapter. The wire of the red connector is connected to the positive pole of the gateway through the terminal, and the wire of the Yellow connector is connected to the negative pole of the gateway through the terminal. -
Page 20: Chapter 3 Initial Configuration
Robustel C9200 User Guide Chapter 3 Initial Configuration The 4G IoT Wireless Gateway can be configured through your web browser that including IE 8.0 or above, Chrome and Firefox, etc. A web browser is included as a standard application in the following operating systems: Windows 7/10, etc. - Page 21 Robustel C9200 User Guide 2. Click the device, right-click to select update driver software, and select Browse my computer for driver software in the pop-up box; 3. Select let me pick from a list of device drivers on my computer;...
- Page 22 Robustel C9200 User Guide 4. Select network adapters in the list and click next; 5. Find Microsoft Corporation in the manufacturer on the left and select Remote NDIS Compatible Device in the right network adapter and click Next. RT_UG_C9200_v.1.0.1 for NA 27 Nov.
-
Page 23: Ip Address Configuration Of Pc End
Robustel C9200 User Guide 6. Select Yes if the following window pops up; 7. After installing the driver, you can view the new network adapter in device manager. 3.1.2 IP address configuration of PC end After the PC successfully loads the network adapter driver, the PC configures its IP address through the following methods: configure a static IP address on the local connection of the PC in the same subnet as the 4G Internet of things wireless communication terminal, and then access the device interface. - Page 24 Robustel C9200 User Guide 2. Click on Properties In the ethernet adapter Status window,; RT_UG_C9200_v.1.0.1 for NA 27 Nov. 2019 24/27...
- Page 25 Robustel C9200 User Guide 3. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties; 4. Click and configure Use the following IP address to manually configure the PC with a static IP address on the same subnet as the address of 4G IoT wireless gateway;...
-
Page 26: Glossary
Robustel C9200 User Guide Glossary Abbr. Description Direct Current Digital Input Ground GPRS General Package Radio Service Global Standard for Mobile Communications IMEI International Mobile Equipment Identification Kbps kbits per second Light Emitting Diode Personal Computer Point-to-point Protocol Personal Identity Number... - Page 27 Robustel C9200 User Guide Glossary Guangzhou Robustel LTD Guangzhou Robustel LTD Address: 3rd Floor, Building F, Kehui Park, No.95 Daguan Road, Add: 3rd Floor, Building F, Kehui Park, No.95 Daguan Road, Guangzhou, China 510660 Guangzhou, China 510660 Tel: 086-20-29019902 Tel:...
