The purpose of this Harbour Acceptance Test is to verify that the
SU90 system provided to the vessel is correctly installed, and fully
functional. It is then ready for the Sea Acceptance Test. When all the
tasks have been done, the report form must be signed by the relevant
parties. The completed document then becomes the official report.
Vessel/Customer
Serial numbers (if applicable)
Processor Unit
Operating Panel
Transceiver Unit
Hull Unit Controller
Hull Unit
Transducer
Simrad SU90
Fish-finding sonar
Harbour Acceptance Test
October 2021 © Kongsberg Maritime AS
409977/C
