  • Page 1 AP12 & AP14H Powerpilot Service Manual...

  • Page 2: Table Of Contents

    Issue 1.0 04/01/00 Simrad Navico Ltd Star Lane, Margate, Kent CT9 4NP, UK Telephone +44 (0) 1843 290290 Facsimile +44 (0) 1843 290471 E-Mail : sales@simrad-navico.co.uk CONTENTS INTRODUCTION 1.1 Electronics PCBs 1.2 Mechanical Components OPERATION ASSEMBLY INSTRUCTIONS Pump Unit Linear Feedback Unit Course Computer Fixed Control Unit Junction Box...

  • Page 3: Introduction

    AP12 & AP14H Powerpilot Introduction...

  • Page 4: Electronics Pcbs

    Issue 1.0 04/01/00 AP12R AND AP14H POWERPILOT The AP12H and AP14H inboard autopilots combine highly sophisticated electronics with advanced software and powerful drives to provide accurate and reliable steering performance under a variety of different conditions with minimal current consumption. AP12H - is suitable for hydraulically steered power boats with a ram capacity of up to 250cc (15 cu in ) with a dashboard mounted control head ((SFC12).
  • Page 5 AP12 & AP14H Powerpilot Calibration...
  • Page 6 Issue 1.0 04/01/00 CALIBRATING THE AP12H AND AP14H Excerpts from the AP12 operation manual - Parameter Adjustment The AP12 uses highly advanced steering software, which constantly assesses how the boat is being affected by the sea conditions. By adjusting its own performance, the pilot is able to maintain the most accurate course for these conditions, just as a human pilot would.
  • Page 7 Issue 1.0 04/01/00 Excerpts from the AP12 operation manual ctd - 6.2 Compass Orientation The SHS12 compass can be mounted pointing four different ways - 0¼, 90¼, 180¼ or 270¼ to the bow (Fig 6.1). ¥ The factory preset is 0¼ (pointing forward). If the compass is mounted pointing any other way, this must be programmed in before using the pilot.
  • Page 8 Issue 1.0 04/01/00 Excerpts from the AP12 operation manual ctd - 2. The Port LED will flash and the Starboard LED will light. If this light sequence is not shown, repeat step 1, holding the but- tons down firmly. 3. Disconnect the SLF12 rod from the ram and pull it fully from the feedback body (the rod is not physically attached to the SLF12 and can be removed easily).
  • Page 9 Issue 1.0 04/01/00 Excerpts from the AP12 operation manual ctd - 6.4 Seatrial / Compass Calibration Before using the AP12, the compass must be calibrated to compensate for any magnetic deviation caused by ferrous or magnetic objects surrounding it on the boat, such as cockpit speakers etc.
  • Page 10 Issue 1.0 04/01/00 Excerpts from the AP14 operation manual - Parameter Adjustment The AP14 uses highly advanced steering soft- ware, which constantly assesses how the boat is being affected by the sea conditions. By adjust- ing its own performance, the pilot is able to maintain the most accurate course for these con- ditions, just as a human pilot would.
  • Page 11 Issue 1.0 04/01/00 Excerpts from the AP14 operation manual ctd - 3.2 Seastate In a rough sea, more heading errors will be detected by the pilot as the heavy seas yaw the boat back and forth. The pilot would normally be overworked trying to correct every error, causing unnecessary strain on the unit and excessive drain on the batteries.
  • Page 12 Issue 1.0 04/01/00 Excerpts from the AP14 operation manual ctd - 6.2 Compass Orientation The SHS12 compass can be mounted pointing four different ways - 0¼, 90¼, 180¼ or 270¼ to the bow (Fig 6.1). ¥ The factory preset is 0¼ (pointing forward). If the compass is mounted pointing any other 0º...
  • Page 13 Issue 1.0 04/01/00 Excerpts from the AP14 operation manual ctd - 6.4 Setting Rudder Limits (AP14H only) This two-stage procedure is used to - ¥ Define the maximum limits of the SLF12 pushrod stroke. ¥ Define the endstop and midstroke position of the rudder. POWER This data is permanently stored, so it will only be neces- sary to repeat this procedure if the SCP12 is replaced or...
  • Page 14 Issue 1.0 04/01/00 Excerpts from the AP14 operation manual ctd - 6.5 Seatrial / Compass Calibration Before using the AP14, the compass must be calibrated to compensate for any magnetic deviation caused by fer- rous or magnetic objects surrounding it on the boat, such as cockpit speakers etc.
  • Page 15 AP12 & AP14H Powerpilot Assembly Instructions...

  • Page 16: Assembly Instructions

    Issue 1.0 04/01/00 ASSEMBLY INSTRUCTIONS 3.1 General Assembly : SRP12 Pump Unit This is supplied as a complete assembly and is not suitable for piece part replace- ment. 3.2 General Assembly : SLF12 Linear Feedback Unit This is supplied as a complete assembly and is not recommended for piece part replacement.
  • Page 17 Issue 1.0 04/01/00 The short screw is used in the front of the case with the longer screws to the flat edge at the rear. 3.7 General Assembly : SHC14 Remote Control Refer to Drawing No. E03709 and fit the cable assembly (E03281) through the case rear (E02737:BK) and grommet (E03701) and terminate it on the PCB.
  • Page 18 AP12 & AP14H Powerpilot Mech Assembly Drawings...

  • Page 21: General Assembly : Junction Box Sjb12

    4.3 General Assembly : Junction Box SJB12...

  • Page 22: General Assembly : Heading Sender Shs12

    4.4 General Assembly : Heading Sender SHS12...

  • Page 24: Circuit Descriptions

    AP12 & AP14H Powerpilot Circuit Descriptions...
  • Page 25 Issue 1.0 04/01/00 CIRCUIT DESCRIPTIONS SCP12 PCB Assembly Introduction. The SCP12 is the heart of the Powerpilot and all other units are linked to it. It decodes the information from the heading sender and calculates the heading, acts upon user commands sent from the control unit, reads the rudder position from the linear feedback unit and controls the drive unit.
  • Page 26 Issue 1.0 04/01/00 is maintained by the microprocessor which provides precision analogue to digital conversion of the feedback signal. Motor Drive. Drive signals are generated by the microprocessor and out- put from ports P1.6 and P1.7, the lines being HIGH for no drive and switch- ing to LOW to provide drive.
  • Page 27 Issue 1.0 04/01/00 SFC12 PCB Assembly Introduction. The Control Unit SFC12 acts as the interface between the Powerpilot and the user via switches, LEDs and a buzzer to facilitate a 2 way flow of information. The circuit diagram for the PCB is given in Drawing No. E02882. Supply and Regulation.
  • Page 28 Issue 1.0 04/01/00 Microprocessor and Reset. Integrated Circuit IC2 is an integrated reset generator for the microprocessor which produces a reset high pulse of approximately 50mS duration at switch on and whenever a 5v supply failure occurs. The microprocessor IC4 either controls or receives data from the remainder of the circuitry as follows: Bus Circuitry.
  • Page 29 Issue 1.0 04/01/00 compared in IC3a and IC3b and the result fed to an XOR gateIC4b. The output of IC4b is held high for the duration of the phase difference across R7 and forms a train of pulses which is developed across C21 R12 to produce a voltage proportional to the phase change.

  • Page 30: Circuit Diagrams

    AP12 & AP14H Powerpilot Circuit Diagrams...

  • Page 31: Circuit Schematics

    Issue 1.0 04/01/00 CIRCUIT DIAGRAMS 6.1 Circuit Schematics SCP12 PCB Assembly E02879 SFC12 PCB Assembly E02882 SHS12 PCB Assembly E02777 SLF12 PCB Assembly E03069 SHC14 PCB Assembly E02552 SJB12 PCB Assembly E02876 6.2 Component Lists and Layouts E02881 sheet 1 SCP12 PCB Assembly Detail E02881 sheet 2 SFC12 PCB Assembly Detail...
  • Page 44 AP12 & AP14H Powerpilot Programming & Configuration...

  • Page 45: Programming And Configuration

    Issue 1.0 04/01/00 PROGRAMMING AND CONFIGURATION This Service Manual only contains programming and configuration information for those features of the autopilot which are not normally available to the end user. For details of normal programming and configuration please refer to the appropriate user manual AP12 AP14...

  • Page 46: Fault Finding

    AP12 & AP14H Powerpilot Fault Finding...

  • Page 47: Common User Faults

    Issue 1.0 04/01/00 FAULT FINDING 8.1 Common User Faults. Excerpt from AP12 manual (faults also apply to AP14) - 7.4 Fault Finding Symptom Probable Cause Remedy Pilot will not enter Auto mode. Rudder limits not entered*. Enter rudder limits* (see 6.3) Rudder limits configuration Check all connections.
  • Page 48 Issue 1.0 04/01/00 Common user faults are included in the LED Diagnostics guide included in the user manual. Excerpt from AP12 manual (faults also apply to AP14) - In the event of the AP12H failing, the LED located under the terminal bay cover of the SCP12 Course Computer can be used to identify the potential source of the problem - Flashes Diagnosis...

  • Page 49: Common Technical Faults

    Issue 1.0 04/01/00 8.2 Common Technical Faults. Symptom Pilot drives in 1 direction only, or no drive at all Probable Cause Blown drive FETs in SCP12 PCB - Commonly due to short circuit on data lines from another unit in the system - usually incorrect wiring by user.

  • Page 50: Spare Parts Packs

    AP12 & AP14H Powerpilot Spare Parts Packs...
  • Page 51 Page 51 Simrad Navico Spares Packs Product - Autopilots AP12 & AP14 Part No. Description Case Top - SCP12 APPK1 Case Bottom - SCP12 APPK2 PCB Assembly - SCP12 APPK3 Drive FET Kit - SCP12 APPK4...
  • Page 52 Page 52 Simrad Navico Spares Packs Product - Autopilots AP12 & AP14 Part No. Description Bottom Case Assembly - SFC12 APPK5 Top Case Assembly - SFC12 APPK6 PCB & Cable Assembly - SFC12 APPK7 Top Case Assembly - SHS12 APPK8...
  • Page 53 Page 53 Simrad Navico Spares Packs Product - Autopilots AP12 & AP14 Part No. Description Bottom Case Assembly - SHS12 APPK9 PCB Assembly - SHS12 APPK10 Top Case Assembly - SHC14 APPK11...
  • Page 54 Page 54 Simrad Navico Spares Packs Product - Autopilots AP12 & AP14 Part No. Description Bottom Case & Cable Assembly - SHC14 APPK12 PCB Assembly - SHC14 APPK13 Pump SRP12 - AP12H & AP14H APPK14 Linear Feedback SLF12 - AP12H & AP14H APPK15...
  • Page 55 Page 55 Simrad Navico Spares Packs Product - Autopilots AP12 & AP14 Part No. Description Rotary Drive SRD12 - AP12R &AP14R APPK16 Manual & SLF12 Fixings - AP12 &AP14 AP12 - APPK17 AP14 - APPK18...

  • Page 56: Technical Notes

    AP12 & AP14H Powerpilot Technical Notes...
  • Page 57 Issue 1.0 04/01/00 10 TECHNICAL NOTES None yet issued.
