- Page 1 Base AXIAL FAN USER’S MANUAL www.ventilation-system.com...
-
Page 2: Table Of Contents
CONTENTS Delivery set ................................................9 Brief description ..............................................9 Operation guidelines ............................................9 Designation key ..............................................10 Installation and set-up............................................. 12 Connection to power mains ........................................14 Electronics operation algorithm ....................................... 16 Technical maintenance ..........................................17 Troubleshooting ..............................................18 Storage and transportation regulations ....................................18 Manufacturer’s warranty .......................................... - Page 3 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the Base unit and all its modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
- Page 4 FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND TROUBLE-FREE OPERATION OF THE UNIT. All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical norms and standards must be observed when installing and operating the unit.
- Page 5 Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it.
- Page 6 characteristics, design, or configuration of its products at any time in order to incorporate the latest technological developments. Never touch the unit with wet or damp hands. Never touch the unit when barefoot.
- Page 7 This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety.
- Page 8 If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a safety hazard. Precautions must be taken to avoid the back-flow of gases into the room from the open flue of gas or other fuel-burning appliances. Ensure that the unit is switched off from the supply mains before removing the guard.
-
Page 9: Delivery Set
DELIVERY SET — 1 pc. Screws and dowels — 4 pcs. Plastic screwdriver (only for the models with a timer T) — 1 pc. User’s manual — 1 pc. Packing box — 1 pc. BRIEF DESCRIPTION The unit described herein is an axial fan for exhaust ventilation of small to medium-sized premises heated during winter. The fan design can also include a non-return valve to prevent back flow when the fan is switched off. -
Page 10: Designation Key
DESIGNATION KEY 100 Base V K Q (220V/60Hz) Power supply parameters other than 220 V/50 Hz _ – 220-240 V/50 Hz (by default) (220V/60Hz) – 220 V/60 Hz Motor modification: L – motor on ball bearings Turbo – high-powered motor Q –... - Page 11 Model 100 Base (-I) 99 mm 140 mm 88 mm 101 mm 103 mm 56 mm 125 Base (-I) 124 mm 165 mm 88 mm 101 mm 125 mm 70 mm...
-
Page 12: Installation And Set-Up
INSTALLATION AND SET-UP Cut off power supply and make sure Remove the front panel of the fan by Mark the holes for fixing the fan and electricity has been turned off. turning it counter-clockwise. the power cable. Lead the power cable to the Fix the fan with the screws. - Page 13 Installation sequence for the decorative panel of the fan To install the decorative panel on the Install the mounts and the decorative Supply power to the fan. fan, remove the plugs. panel. The decorative panel is not included in the delivery set, and is purchased separately for the fan. R 600 The unit with a protection rating against access to hazardous parts and water ingress IP24 is allowed to be installed in zones...
-
Page 14: Connection To Power Mains
CONNECTION TO POWER MAINS The fan is rated for connection to single-phase AC 220-240 V/50 (60) Hz power mains. Terminal designations on wiring diagrams: LT— timer control line — line — ON\OFF switch QF— automatic circuit breaker — neutral Base(-I) Base(-I) VT/VTH 2min 30min... - Page 15 Base(-I) T/TH 2min 30min Base(-I) V DO NOT USE A METAL SCREWDRIVER, KNIFE, ETC. FOR ADJUSTMENT OPERATIONS NOT TO DAMAGE THE CIRCUIT BOARD.
-
Page 16: Electronics Operation Algorithm
ELECTRONICS OPERATION ALGORITHM The fan with the timer T is started after actuation of the external switch, e.g. the light switch. The control voltage is supplied to the input terminal LT (ST). After the control voltage is off, the fan continues to operate within the set time period adjustable from 2 to 30 minutes by the timer. -
Page 17: Technical Maintenance
TECHNICAL MAINTENANCE The fan maintenance periodicity is at least once per 6 months. Maintenance steps: Disconnect the fan from power supply and make sure Clean the fan with a soft dry cloth or a brush. electricity has been turned off. Remove the front panel. Wash the front panel under running water. -
Page 18: Troubleshooting
TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line No power supply. is connected correctly, otherwise When the unit is connected to power mains, the fan does not rotate and troubleshoot the connection error. does not respond to any controls. Internal connection fault. -
Page 19: Manufacturer's Warranty
MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/ EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 20 • Redesign or engineering changes to the unit. • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. •...
- Page 21 Quality Inspector’s Stamp Sold by (name and stamp of the seller) Manufacture Date Purchase Date...
- Page 24 Certificate of acceptance Base turbo (220V/60Hz) Base-I The fan is recognized as serviceable. V160-1EN-06...
