SmartCode at a Glance
Exterior
"Lock"
button
Keypad
Keyway
SmartKey
tool hole
Switches and Status LED colors
These features can be adjusted in some smart home apps. Once the associated functions are set by Zigbee,
the setting of switches #1, 2 & 3 no longer affect the lock operation until factory reset.
Switches
On Off
1 2 3 4
Switch Function
Door lock status LED blinks every 6
1
seconds
Lock automatically re-locks door 30
2 seconds after unlocking. Disabled if no
codes are programmed.
3 Audio
4 Not used.
Deleting a single user code (manually at the lock)
Note: All codes may be deleted at once if the mastercode is enabled. For more information about the
mastercode, consult the SmartCode 914 Programming and Troubleshooting Guide at www.kwikset.com.
1 Keep door open. 2 Press "Lock"
Press "Program" button once.
button once.
5 Re-enter user code. 6 Press "Lock"
button once.
If no button is pressed for five seconds, the system will time out, and
you will need to restart the procedure.
Network Information
ZigBee System Notes
ZigBee is a "Wireless mesh network," and results may vary
based on building construction and communication path,
with 35+ feet being typical installed distance in a standard
home environment and 250 feet+ when the lock has a clear
line of sight with the smart home controller or hub. It may be
necessary to install additional ZigBee devices to enhance the
communication path between the lock and controller/hub for a
more robust ZigBee network.
Removing the lock from the network
Press button "B" on the lock interior nine times.
Reference Guide
Interior (cover removed)
Back
panel
Button "A" Button "B"
"Program"
button
Switches
Status
LED
Turnpiece
shaft
Note: When the cover is removed,
the turnpiece shaft can be used to
manually lock and unlock the door.
Status
LED
Color Lock Status
Blinking green Unlocked
Blinking amber Locked
Blinking red Low battery
Door handing process
did not work properly.
Solid red See the online
Programing and
Troubleshooting Guide.
3 Enter user code 4 Press "Lock"
to be deleted. button once.
If unsuccessful
Test code
Make sure to enter
While the door is
the same valid code
open, test the user
in steps 3 and 5.
code to make sure
it no longer unlocks
the door.
SmartKey Re-Keying
Re-key the lock to work with your existing key. See the supplied
SmartKey Re-key instructions for more information.
Note: If Auto-Lock is enabled (see "Switches and Status LED
Colors"), remove the battery pack before re-keying your lock.
System Alerts
Alert Reason
Keypad flashes red once with
One incorrect code entered.
one beep*.
No user code programmed.
Keypad flashes red three Programming timeout after five
times with three beeps*. seconds.
Unsuccessful programming.
Keypad flashes red 15 times Three incorrect codes entered
with 15 beeps* within one minute.
Keypad flashes red with fast
beeping sound for three to Low battery.
four seconds.
Keypad flashes red with
Door jammed while attempting
continuous beeping sound
to lock.
for two seconds.
Interior assembly is
Lock beeps continuously.
disconnected from exterior.
*Beeping sound will only be heard if switch #3 is on.
Troubleshooting
A complete SmartCode 914 Programming and
Troubleshooting Guide is available at www.kwikset.com.
Factory Reset
A factory reset will delete all codes associated with the lock,
and it will remove it from your smart home system.
1 Remove 2 Press and HOLD the "Program"
battery pack.
3 Press the "Program"
button once more. When
the LED flashes green and
you hear one beep, the
lock has been reset.
Important Safeguards
1.
2. Familiarize yourself with all warning and caution statements.
3. Remind all family members of safety precautions.
4. Protect your user codes and mastercode.
5. Dispose of used batteries according to
CAUTION: Prevent unauthorized entry. Since anyone with
access to the back panel can change the user codes, you
must restrict access to the back panel and routinely check
the user codes to ensure they have not been altered without
your knowledge. The use of a mastercode can help protect
your system's settings.
WARNING: This Manufacturer advises that no lock can
provide complete security by itself. This lock may be
defeated by forcible or technical means, or evaded by
entry elsewhere on the property. No lock can substitute
for caution, awareness of your environment, and
common sense. Builder's hardware is available in multiple
performance grades to suit the application. In order to
enhance security and reduce risk, you should consult a
qualified locksmith or other security professional.
©2021 Spectrum Brands, Inc. All Rights Reserved. Lake Forest, CA 92610.
4 / 4
Solution
Re-enter code.
Program at least one user code.
Attempt programming procedure again.
Re-enter code after 60 second keypad
lockout.
Replace batteries.
Manually re-lock door. If needed,
reposition strike.
Remove battery pack, reconnect the interior
to the exterior, then reinstall battery pack.
button while reinserting
the battery pack.
Keep holding the button for 30
seconds until the lock beeps
and the status LED flashes red.
Status
LED
4 Perform the door handing process again
to teach the lock the orientation of the
door, pair the lock with your smart home
system, and add user codes to your lock.
Read all instructions in their entirety.
local laws and regulations.
