Kwikset SMARTCODE 914 Installation And User Manual page 3

7
Pair the lock with your smart home system
A
Initiate the pairing process through your smart
home system (either through your smart home
app, at your panel, or at your controller or hub).
Refer to your smart home system
instructions for more information.
B
You may be prompted by your smart home
system to scan the QR code on the interior
assembly. If not, proceed to step C.
8
Add user codes (30 maximum)
It is recommended that you add and delete all user codes through your smart home system.
If your system does not allow this, codes may be added directly to the lock as shown here.
A
Programming information
Mastercode: For enhanced security, a
mastercode may be used when adding
and deleting user codes. For more
information about the mastercode,
download the SmartCode 914
Programming and Troubleshooting Guide
at www.kwikset.com.
Programming Timeout: During
programming, if no button is pressed
for five seconds, the system will time
out (indicated by three beeps and a red
flashing keypad), and you will need to
restart the procedure.
E
What lights and sounds does the lock produce?
One green flash with one beep
9 Test the lock and check door alignment
A
With the door open, press the "Lock"
button. Confirm that the door locks.
Install the interior cover
10
Important Information about the interior cover
window
The window
on the interior
cover is locked
by default to
prevent someone
from tampering
with your lock's
settings.
Cover Installation
a
Install cover.
Note: You may
need to rotate
the turnpiece to
align with the
turnpiece shaft.
turnpiece
C
When prompted by your smart home
system to initiate pairing at the lock, press
button "A" on the lock interior four times.
button "A"
B
Make sure the door is open.
Press the "Program" button once.
green
1x
Programming was successful.
B
Enter the user code(s) added
in the previous step. Confirm
that the door unlocks.
If you wish
to unlock the
window, you can
slide it up for
more convenient
access to the
programming
buttons while the
cover is installed.
b
Install
screws.
69316
(3x)
For Lock Bag
turnpiece
shaft
D
E
button "B"
ZID:
0123456789ABCDEF
INSTALL CODE:
0123456789ABCDEF0123456789ABCDEF
QR code
C
Enter a new user code. A total of 30
user codes may be programmed.
Each user code must
be a unique code
between 4 and 8
digits, depending
on your smart
home system.
Three red flashes with three beeps
or
Move swiftly through
programming, as the system
will time out if no button is
pressed for five seconds.
*Beeping sound will only be heard if switch #3 (on the lock interior) is in the on positon.
C
Close the door. Press the "Lock"
button. Confirm that the door
locks smoothly without error.
To unlock
the window,
remove the
security screw.
Battery Pack Access
If the window is unlocked,
remove the window to
access the battery pack.
If the window is locked, remove
the interior cover and screws
to access the battery pack.
3 / 4
If the pairing process is successful, re-name
the lock in your system (if applicable).
If the pairing process is unsuccessful,
press button "B" nine times.
Perform steps 7A-7D again.
If still unsuccessful, follow your smart home system's
instructions to remove (exclude/unpair) the lock from
any other network. Then perform steps 7A-7D again.
D
Press the "Lock" button once.
red
3x
Programming was unsuccessful.
Make sure the user code is Make sure the lock has room
not a duplicate and that it for an additional code. If all user
is between 4 and 8 digits code positions are filled, delete a
during your next attempt. code to make room for this one.
D
If your does not lock smoothly,
make sure you replaced your
previous latch and strike with
those supplied in the box.
If you still experience locking
errors, call Kwikset Support to
order a Warped Door Service Kit.
Kwikset Support: 1-866-863-6584
For Lock
(3x)
Bag
69316
actual size
