Reference Section

14.1

Display Mapping

Display Mapping
Display Point
1-16
17-18
19
20
21-32
32
33
34
35
36
37
38
39
40
41
42
43
Display 1
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60-64
Display Point
1-32
Display 2
33-64
Display Point
1
Display 3
2
3
Description
Discrete Alarms
Base Controls
Master Trigger Control
Device Reset Control
Undefined
(33) Default Configuration
(34) DIP Switch Configuration
(35) MAC Address not set
(36) IP address not set
(37) LAN hardware error
(38) SNMP processing error
(39) SNMP community error
(40) LAN TX packet drop
(41) Notification 1 failed
(42) Notification 2 failed
(43) Notification 3 failed
(44) Notification 4 failed
(45) Notification 5 failed
(46) Notification 6 failed
(47) Notification 7 failed
(48) Notification 8 failed
(49) NTP failed
(50) Time Tick
(51) Serial 1 receive queue full
(52) Dynamic memory full
(53) Unit reset
(54) DCP poller inactive
(55) TRIP error
(56) No dial tone
(57) Modem failed
(58) Meter 1 failed
(59) Meter 2 failed
(60) Meter 3 failed
Reserved
Description
Ping Alarms 1 - 32
Undefined
Description
Analog 1 Minor Under
Analog 1 Minor Over
Analog 1 Major Under
