DPS Telecom NetGuardian SUI User Manual page 18

14
name and icon do not affect your ability to connect to
the unit.
15. Select the following COM port options:
• Bits per second: 9600
• Data bits: 8
• Parity: None
• Stop bits: 1
• Flow control: None
Once connected, you will see a blank, white
HyperTerminal screen. Press Enter to activate the
configuration menu.
17. The NetGuardian SUI's main menu will appear. Type
C for C)onfig, then E for E)thernet. Configure the unit's IP
address, subnet mask, and default gateway.
Now you're ready to do the rest of your configuration via LAN. Please refer to the next section "...via LAN" for
instructions on setting up your LAN connection.
Device Manager.
16. When prompted, enter the default user name
admin and password dpstelecom. NOTE: If you
don't receive a prompt for your user name and
password, check the Com port you are using on your
PC and make sure you are using the cable provided.
Additional cables can be ordered from DPS Telecom.
18. ESC to the main menu. When asked if you'd like
to save your changes, type Y for Y)es. Reboot the
NetGuardian SUI to save its new configuration.
