CHARACTERISTICS:

The HD67E15-A1 are EtherCAT / IEC61850 - Converters.
It allows for the following characteristics:
Isolation between EtherCAT – IEC61850 – Power Supply;
Two-directional information between EtherCAT bus and IEC61850 bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67E15 software on your PC in order to perform the following:
Define the parameters of EtherCAT line;
Define the parameters of IEC61850 line;
Define EtherCAT variables to read and write;
Define the list of IEC61850 variables available for the Client;
Export the ESI file for configuration of EtherCAT Master;
Update the device.
