Datacryptor Ethernet User Manual
Beneath the front panel diagram are five large buttons that provide direct access to
•
management facilities (see the
Pressing F5 while using the Front Panel Viewer will cause a refresh of all
Note:
displayed settings from the unit.

User Key Material

Adminv2.usr
Adminv3.usr

The Front Panel LEDs

The Front Panel LEDs indicate the state of the unit.
Indicator Light
Power (green)
Network (green)
Error (red)
10M (100 Mb
Ethernet unit only)
Loopback (yellow)
(1 Gig and 10 Gig
Ethernet units only)
Alarm (red)
Encrypt (green)
Plain (red)
Host (green)
1270A450-005 - June 2008
All manuals and user guides at all-guides.com
Front Panel Viewer buttons
User key material (containing public and secret keys of user)
protected by a default password of: PASSWORD
Alternative user key material (containing public and secret keys of
user) protected by a default password of: 11aaBB!!PASS
State Indication
On Unit is powered on
Off No power
On Normal operation
Fast Flash Link Down
Slow Flash Not used
Off Loss of Signal, Loss of Synchronization
On Errors have occurred
Fast Flash New errors in log
Off No errors
Off 100 Mbps operation
On 10 Mbps operation
Off Normal operation - no loopback enabled
Slow flash Host loopback enabled
Fast Flash Network loopback enabled
On Host and Network loopback enabled
On Unit is alarmed - Hardware fault
Fast flash Unit is not commissioned
Off No Alarm
On Unit is in Encrypt mode
Slow flash Standby
Off Unit is not in Encrypt mode
Fast Flash Unit is in Plain mode
Off Passthrough mode not selected
On Normal operation
Element Manager Reference
section below).
