Element Manager Reference

Front Panel Viewer

A splash screen is displayed when you attempt to connect to a Datacryptor Ethernet unit. This
process should normally complete within a few seconds but might take up to one minute. You
can abort the connection attempt from the splash screen by pressing its Cancel button. Note
that the text on the splash screen may change from "Identifying unit" to "Fetching unit
information" during the connection process.
The splash screen closes and the Front Panel Viewer is displayed when you successfully connect
to a Datacryptor Ethernet unit, to display its status and provide access to the management
facilities. There are some differences between the Front Panel Viewer for the 100 Mb Ethernet,
the 1 Gigabit and the 10 Gigabit Ethernet Datacryptors. The three variations are shown below:
Page 38
