Datacryptor Ethernet User Manual
7. At the IPCONFIG> prompt, type:
SET <port> <ip address> <subnet mask>
where: <port> identifies the port to be set and is one of the following:
− NETWORK (public network port),
− CONTROL (serial control port),
− ETHERNET (Ethernet management port).
<ipaddr> is IP address of a subnet to be added or deleted.
<netmask value> is netmask of the subnet.
Examples
Set Control 2.2.2.2 255.255.0.0
Set network 3.4.5.6 255.255.0.0
- No two IP addresses should be the same
Note:
- IP addresses of 127.x.x.x are not allowed.
- Net masks of 0.0.0.0 and 255.255.255.255 are not allowed.
- Public and Private port addresses must be valid Class A, B or C addresses. For
this reason subnet masks must comprise of consecutive
side when represented in binary, for example 255.255.1.0 is invalid.
To make the unit request an Ethernet Management Port IP address from a DHCP/BOOTP server
on the LAN, set its Ethernet Management Port IP address to 255.0.0.0 and net mask to
255.255.255.255 (this is an exception to the rule mentioned in the note above).
To reset the addresses to factory defaults, use the DEFAULT command.
The above section details the steps necessary to connect via the Ethernet management port.

Dial Up Networking

It is also possible to connect and run the Element Manager program via the serial Control port
using Dial up Networking.
1. Ensure a serial cable is connected between your PC and the Datacryptor Ethernet unit.
2. Use the Networking wizard for your operating system to generate a Dial up connection;
the following parameters should be used for the settings:
− Set up an advanced connection
− Connect directly to another computer
− Guest
− Connection Name
− Select the Com port to which you have connected the serial cable
− All users
− User Name and Password
3. Select the option for Desktop shortcut.
4. Select Finish.
1270A450-005 - June 2008
All manuals and user guides at all-guides.com
Sets the Control (serial port) IP Address to 2.2.2.2
Sets the network port IP Address to 3.4.5.6
255.255.0.0
Connecting to Datacryptor Ethernet Units
s from the left hand
1
