Connecting to Datacryptor Ethernet Units
5. Click on the shortcut to launch the connection.
6. Select the Properties button.
7. On the General tab confirm correct connection.
8. Click Configure button and use the menu to set the maximum connection speed of
115200 bps. Set the flow control to none; the Ethernet and SONET do not support flow
control.
9. On the Network tab, select TCP/IP and click Properties - enter the address 2.2.2.1.
10. Close down the Properties and click Connect.
11. A connection with the Datacryptor Ethernet will be made. Ensure the connection is made
then disconnect.

Adding a Unit to Element Manager

Once the Management or Dial up connection is set up, you can connect to each Datacryptor
Ethernet unit by adding an icon in the Element Manager. The Dial Up connection created earlier
must be running if a serial connection is to be used.
1. Start the Element Manager, e.g. by double-clicking its icon:
2. The Element Manager Main Window will be displayed:
3. Add a new Datacryptor Ethernet unit by clicking on the New Unit icon
the New Unit option from the File menu. This will launch the Add a New Unit Wizard:
Page 28
All manuals and user guides at all-guides.com
Datacryptor Ethernet User Manual
or selecting
