Dave Embedded Systems AXEL ULTRA Hardware Manual page 17

A x e l H a r d w a r e M a n u a l
Feature
Networks
CAN
SD/MMC
Storage
Serial buses
Audio
Timers
RTC
Watchdog
Debug
Tab. 4: Peripherals
Feature
Supply Voltage
Active power
consumption
Dimensions
Weight
MTBF
Operating
temperature
range
Shock
Vibration
Connectors
Connectors
16/80
Specifications
(interrupts available)
Gigabit Ethernet 10/100/1000 Mbps with
integrated PHY
2x CAN 2.0B ports (1x with integrated PHY)
4x SD 3.0 /SDIO 3.0/MMC 4.x compliant
controllers
Serial ATA II 3.0 Gbps with integrated PHY
5x full-duplex SPI ports with four peripheral
chip selects
3x master and slave I²C interfaces
3x I²S/SSI/AC97 interfaces
Enhanced Periodic Interrupt Timer
General Purpose Timer
On board, ±3.5ppm (DS3232), external battery
powered
On board, configurable timeout (MAX6373)
JTAG IEEE 1149.1 Test Access Port
CoreSight™ and Program Trace Macrocell
(PTM)
Specifications
2.8-4.5V wide range input, voltage regulation
on board
See section 8.3 - Power consumption
85mm x 50mm
<tbd>
<tbd>
Commercial: 0°C / +70°C
Industrial: -40°C / +85°C
100 G
<tbd>
3 x 140 pins 0.6mm pitch
<tbd>
October, 2016
v . 1 . 0 . 5
Options
Options
