GAS SUPPLY

• With the installation of this conversion kit,
the cooktop should operate on LP gas at 10
of water column pressure.
• The pressure regulator must be connected in series
with the manifold of the cooktop and must remain
in series with the supply line. For proper operation,
the maximum inlet pressure to the regulator must
be no more than 14 water column pressure for
LP gas.
• When checking the regulator, the inlet pressure
must be at least 1 greater than the regulator output
setting. If the regulator is set for 10 of water column
pressure, the inlet pressure must be at least 11.
IMPORTANT –
the individual shut-off valve from the gas supply piping
system during any pressure testing of that system at test
pressures greater than 1/2 psig. Isolate the cooktop from
the gas supply piping system by closing the individual
manual shut-off valve to the cooktop during any pressure
testing of the gas supply piping system at test pressures
equal to or greater than 1/2 psig.
TURN OFF GAS AND
ELECTRIC SUPPLY
BEFORE YOU BEGIN, TURN OFF THE GAS SUPPLY AT
THE SHUT-OFF VALVE. DISCONNECT THE ELECTRICAL
SUPPLY FROM THE COOKTOP.
Shut-off valve
LP Conversion Instructions
Disconnect the cooktop and
Electrical supply

CONVERT THE PRESSURE REGULATOR

1
Locate the pressure regulator under the front
A
of the cooktop.
Remove the nut from the pressure regulator with
B
an adjustable wrench.
Natural gas
Nut
LP gas
Twist and remove the conversion plug from the inside
C
of the nut. Flip the conversion plug over; then insert,
twist and lock it back into place in the nut.
Natural gas
Reinstall the nut onto the regulator.
D
Apply the LP Conversion label next to the Rating Plate.
E
31
LP gas
Nut
