Summary of Contents for Getac K120
Page 1
Getac K120 Self-Maintenance Manual...
Page 2: Table Of Contents
KB Dock Keyboard (P/N 531014200S01) KB Dock Front Corner (P/N 344142000058 & 344142000059) KB Dock Rear Corner (P/N 344142000060 & 344142000061) KB Dock Handle (P/N 451142000K03) | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 3
K120 Tablet...
Page 4: Smart Card Door (P/N 340142000012)
Smart Card Door (P/N 340142000012) 1. Unlock the two screws, and then open the door, and remove the smart card door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 5
Audio Door (P/N 340142000068) 1. Unlock the two screws, and then open the door, and remove the audio door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 6: Option Door(P/N 340142000010)
Option Door(P/N 340142000010) 1. Unlock the two screws, and then open the door, and remove the audio door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 7: Dc Door (P/N 340142000009)
DC Door(P/N 340142000010) 1. Unlock the one screw, and then open the door, and remove the option door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 8
SSD Canister (P/N 581114200006) 1. Remove the two screws (371102010432) and one screw (371102610025) lock the SSD cover. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 9
SSD Canister (P/N 581114200006) 2. Remove the SSD cover and lever.. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 10
SSD Canister (P/N 581114200006) 3. Remove the SSD and connect board. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 11
K120 Keyboard Dock...
Page 12: Kb Dock Lan Door (P/N 340142000025)
KB Dock LAN Door (P/N 340142000025) 1. Unlock the screw, and then open the door, and remove the KB Dock LAN Door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 13: Kb Dock Usb X2 Door (P/N 340142000026)
KB Dock USB X2 Door (P/N 340142000026) 1. Unlock the screw, and then open the door, and remove the KB Dock USB X2 Door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 14: Kb Dock Only Rs232 Door (P/N 340142000027)
KB Dock ONLY RS232 Door (P/N 340142000027) 1. Unlock the screw, and then open the door, and remove the KB Dock ONLY RS232 Door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 15: Kb Dock Hdmi&Dp Door (P/N 340144600007)
KB Dock HDMI&DP Door (P/N 340144600007) 1. Unlock the screw, and then open the door, and remove the KB Dock HDMI&DP Door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 16: Kb Dock Dc Jack Holder And Door (P/N 581114010011&344857100028)
KB Dock DC Jack Holder and Door (P/N 344857100028 & 581114010011) 1. Unlock the screw, and then open the door, and remove the KB Dock DC Jack Holder and Door | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 17: Kb Dock Keyboard (P/N 531014200S01)
KB Dock Keyboard (P/N 531014200S01) 1. Remove two screws (371102600001) lock the keyboard cover. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 18
KB Dock Keyboard (P/N 531014200S01) 2. Remove seven screws (371102010432) lock the keyboard cover. Then remove the keyboard cover. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 19
KB Dock Keyboard (P/N 531014200S01) 3. Remove two screws (371102010066) lock the keyboard. Then slightly lift up the keyboard. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 20
KB Dock Keyboard (P/N 531014200S01) 4. Remove four screws (371102010432) lock the keyboard FPC cover, then remove the keyboard FPC cover. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 21
KB Dock Keyboard (P/N 531014200S01) 5. Disconnect the keyboard FPC, then remove the keyboard.. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 22
KB Dock Keyboard (P/N 531014200S01) 1. Remove two screws (371102600001) lock the keyboard cover. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 23: Kb Dock Front Corner (P/N 344142000058 & 344142000059)
KB Dock Front Corner (P/N 344142000058 & 344142000059) 1. Remove three screws (371102600001) lock the left foot, then remove the left foot. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 24
KB Dock Front Corner (P/N 344142000058 & 344142000059) 2. Remove three screws (371102600001) lock the right foot, then remove the right foot. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 25: Kb Dock Rear Corner (P/N 344142000060 & 344142000061)
KB Dock Rear Corner (P/N 344142000060 & 344142000061) 1. Remove the eight screws (371102600001) lock the corners. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 26
KB Dock Rear Corner (P/N 344142000060 & 344142000061) 2. Remove the two screws (342830700019) and two screws (371103010070) lock the corners, then remove the corners. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 27: Kb Dock Handle (P/N 451142000K03)
KB Dock Handle (P/N 451142000K03) 1. Remove the eight screws (371102600001) lock the corners. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 28
KB Dock Handle (P/N 451142000K03) 2. Remove the two screws (342830700019) and two screws (371103010070) lock the corners, then remove the corners. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 29
KB Dock Handle (P/N 451142000K03) 3. Remove the handle. | Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
Page 30
THANK YOU FOR YOUR ATTENTION THANK YOU FOR YOUR ATTENTION Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
