G2S A20 / G2S C20 Quick Operation Manual
1. Button Functions
Mute Button: Press it to mute alarms
Knob: Start treatment and adjust device settings
Ramp Button: Press it to enable the Ramp feature
2. Setting up the Device
Power Cord
Power Outlet
E
A. Connect one end of the tube to the assembled mask.
B. Connect the other end of the tube securely to the air outlet of the device, as shown in the figure
above.
C. Connect the power adapter to the DC inlet of the device.
D. Connect the power cord to the power adapter.
E. Plug the power cord into the power outlet.
3. Adjusting Device Settings
A. After the device is connected to power, its screen displays the Main Interface shown in the figure
below.
B. From the Main Interface shown above, press and hold the Ramp Button
seconds. The screen displays the Initial Setup Interface, as shown in the figure below.
C. Press
the Knob
to access the Setup Interface, as shown in the figure below.
All manuals and user guides at all-guides.com
G2S A20 / G2S C20 Quick Operation Manual V1.0
A
Mask
Tube
Power Adapter
D
1 / 2
B
Air Outlet
C
Device
DC Inlet
Filter Cap (Air Inlet)
for three
