88503595 C
Kitchen Cart with Solid Wood
Drop Leaf and Two Door
Dear Our Valuable Customers,
Please follow our assembly instructions in every step,
we guarantee that you will get the perfect merchandise.
Thank you so much for purchasing our quality products.
Casual Attire For Today's Home
PART LIST
A.
Top
1 pc.
F.
G.
Bottom
Middle
1 pc.
Back Stretcher
1 pc.
K.
Door
2 pcs.
HARDWARE LIST
Head Cap Bolt
20 pcs.
(+1 Extra)
Caster
2 with brake and
2 without brake
4 pcs.
Tools Required For Assembly : Philips screwdriver
B.
Side Frame
1 pc.
Back Stretcher
L.
Drawer(Knock-Down Construction please
refer how to assemble the drawer
on the last page of this assembly
instruction)
1 pc.
Machine Screw
Hex Wrench
for Pull Handle
1 pc.
6 pcs.
D.
C.
Upper
Side Frame
Back Stretcher
1 pc.
1 pc.
H.
Back Panel
Lower
1 pc.
1 pc.
Pull Handle
2 pcs.
(A)
Wood Screw
8 x ½"(for Caster)
Wood Plug
16 pcs.
10 pcs.
(+2 Extra)
(+1 Extra)
Thai Patent Numbers 15271
Front Rail
I.
Fix Shelf
N.
Round Arm
1 pc.
M.
Handle Arms
2 pcs.
(B)
Wood Screw 6 x 1"
Long (for Side Part
Drawer)
Pull Handle
8 pcs.(+1 Extra)
2 pcs.
(C)
Wood Screw 6 x ½"
Short (for Bottom Part
Drawer)
6 pcs.(+1 Extra)
E.
1 pc.
J.
1 pc.
Advertisement
Related Manuals for Home Styles 88503595 C
Summary of Contents for Home Styles 88503595 C
- Page 1 88503595 C Kitchen Cart with Solid Wood Drop Leaf and Two Door Dear Our Valuable Customers, Please follow our assembly instructions in every step, we guarantee that you will get the perfect merchandise. Thank you so much for purchasing our quality products.
- Page 2 Assembly Instructions 2/4 IMPORTANT Do not tighten up all the screws until each part is properly assembled. You should keep Hex Wrench in the safe place as you may need to tighten up the Head Cap Bolts in the future. STEP 1 Attach 4 Casters to the side of the Bottom (F) with Wood Screws(A),...
- Page 3 Assembly Instructions 3/4 STEP 4 Attach the Handle Arms (M) using Head Cap Bolts from the inside and slide the Round Arm (N) in place. Attach the Door (K) to the Fix Shelf (J) and Bottom (F) using Spring Pin Hinge. Attach the Door and Drawer Pull Handles using the Machine Screws.
- Page 4 Assembly Instructions 4/4 Drawer (Fig)1 (Fig) 1 Line up Side Parts (L3)and(L4)to the Front Part (L1) and Back Part (L2). Be sure to follow the ‘Arrow’ sign sticker on the parts. Using a Phillip’s screw driver, insert 1” screws MAKE SURE ROLLER IS ON THE BACK (B)into each of the 4 pre-drilled holes in sides (L3)and(L4), then tighten half way.
