Auto Start Checked
Unchecked
Advanced
Checked
Settings
Unchecked
Enable Serial Checked
Console
Unchecked
Display Setup
Resolution AUTO
NTSC
PAL
Set Display
Button
Device Management
Set Device
Name Button
New device
Name
Set Password
Button
New password
Password again
Set SNTP Button
Enable SNTP True
False
America/Chicago
Time Zone
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Check this box to set the system to automatically start
encoding upon powering on.
Check this box for advanced encode settings to appear on
the channel tab.
Check this box to enable the serial console over the front
panel 2.5mm serial port.
Selects the desired resolution for Composite pass-through
output.
Click once the desired selection is made in the Resolution
dropdown menu to make real time changes.
Sets a custom name for the camera to appear in the user
interface.
Text box to enter desired device name.
Sets a password to limit access to the user interface.
Text box to enter new password.
Text box to re-enter new password.
Must match previous field.
Click this button to access Simple Network Time Protocol
(SNTP) configuration options.
Sets whether Simple Network Time Protocol (SNTP) is
enabled.
Allows for selection of desired time zone.
