RPS Software User Instructions
4K HEVC/H.265 & H.264 Encoding Systems
Rapid Production Starter Kit Software
Model Names:
HE4K-DCK-RPS
HE2K-DCK-RPS
FV2K-DCK-RPS
FV4K-DCK-RPS
DOC-USR-0110-02
Manual Version 2.0.0
December 5, 2018
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2018 Z3 Technology, LLC. All rights reserved.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Z3 Technology HE4K-DCK-RPS
Summary of Contents for Z3 Technology HE4K-DCK-RPS
- Page 1 Copyright © 2018 Z3 Technology, LLC. All rights reserved. This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at any time and without notice.
- Page 2 CONFIDENTIAL DOC-USR-0110-02 REVISION HISTORY Version Date Change Note Author 1.0.0 10/24/2016 Original Document 2.0.0 12/05/2018 Added nfs and web overview ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702...
-
Page 3: Table Of Contents
Method 2: Running Your code through TFTP/NFS ............13 APPENDIX A: Troubleshooting ..................14 APPENDIX B: Set up Terminal Window ................15 ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... - Page 4 Figure 1 Sample Content of Images Directory after Successful Build ..........7 Figure 2 System Setup Tab ....................11 Figure 3 Updater Screen ....................12 Figure 4 Example File Selection Screen .................. 12 ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702...
-
Page 5: General Description
Those customers that license the optional source code package can also receive source code for Z3’s demonstration applications, providing an ideal starting point for custom applications. Z3 Technology can provide services to customize the software applications to a customer’s specification. For design services or additional support, please contact Z3 at www.Z3technology.com... -
Page 6: Making The Directories And Running The Make Script
On a PC running Linux, create a directory where the released materials are going to be located: ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 7: Figure 1 Sample Content Of Images Directory After Successful Build
The result should be something like the following. Note that actual filenames, dates, and times will differ. Figure 1 Sample Content of Images Directory after Successful Build ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 8: Code Overview
The web ui directory is located under z3apps/webgui/gui this contains relevant files to the client side implementation. The server implementation is done using a lua based web server called ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 9: Z3 Application Overview
(1) With the serial console connected reboot the board and interrupt the boot in u-boot by pressing any key. If successful the following will be seen: U-Boot 2010.06-dirty (Apr 05 2016 - 16:08:07) ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 10: Access The Http-Based User Interface
5.2.2 Using ZFinder ZFinder is a PC utility that allows you to find any Z3 Technology product on your network. If you have not yet downloaded this to your computer, you can find this program on your customer account on Z3’s support server or at Z3Cam-4K.Z3technology.com. -
Page 11: Running The Code You Built On The Board
Figure SEQ Figure \* ARABIC 2 Updating the Device Firmware from the User Figure 2 System Setup Tab Interface (3) This brings you to the update image screen. In this screen, click on “Browse…” ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 12: Figure 3 Updater Screen
(6) You will see screens stating that the image is being uploaded and that the flash is being updated. After about one minute, the main menu will appear again. (7) Your Z3 hardware is now updated. ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 13: Method 2: Running Your Code Through Tftp/Nfs
(d) Create symbolic links in your top-level directory to allow access to your filesys and images directory (note: actual directory name may be different depending on your specific release): # cd /home/z3/z3-cam ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 14: Appendix A: Troubleshooting
- Do the encoder IP address and the PC IP address have the same first two values (or, if netmask is set to 255.255.255.0, the same first three values)? ___________________________________________________________________________________________ Z3 Technology, LLC ♦ 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702... -
Page 15: Appendix B: Set Up Terminal Window
When contacting Z3 Support for additional support, please send a log file of the serial output to Z3 Technology. Z3 Technology’s Express Limited Warranty will be void if the label on the hardware bearing the Serial Number is removed, tampered with or defaced. You can view Z3 Technology’s full hardware warranty at http://z3technology.com/Support/OEM-HW-...
