TCL LinkHub User Manual page 13

PPPoE
Static IP
MAC Clone
When the MAC Clone function is enabled, multiple client devices can connect to the CPE and
access the internet.
Your current MAC address is displayed in this option. Click Reset to set a new MAC address.
Click Clone to copy your host MAC address.
LAN
The default gateway address is 192.168.1.1, and the default subnet mask is 255.255.255.0.
With the DHCP Server function enabled, IP addresses will be assigned automatically to client
devices in the network. If the DHCP Server function is disabled, the CPE will not assign IP
addresses to the connected client devices. The IP address must be entered on each client
device.
Wi-Fi
Basic
Configure basic Wi-Fi settings in this option.
SSID
SSID Broadcast
Security
Encryption
Password
Advanced
Configure advanced Wi-Fi settings in this option.
Point-to-Point Protocol over Ethernet (PPPoE) is a network protocol
that is mainly used for DSL services whereby individual users connect
to a modem using an Ethernet connection.
Enter the username and password provided by your network service
provider, and click Apply.
Access the internet using a fixed IP address, subnet mask, gateway
IP address and Primary DNS server. These information should be
provided by your network service provider.
SSID is the name of the Wi-Fi network, and is 1 to 32 characters long.
This function is enabled by default.
When this function is disabled, other users cannot detect the SSID or
the Wi-Fi name. They need to manually enter SSID to connect to your
CPE network.
The available security modes include Disable, WEP, WPA, WPA2, and
WPA/WPA2.
The available options inclue TKIP, AES, and Auto.
Check the Wi-Fi password in this item.
13
