- Page 1 OPERATING INSTRUCTIONS AirSafe 2 Ex CONTINUOUS AMBIENT AIR DUST MONITORING ENVEA Process GmbH - Gutedelstraße 31 – 79418 Schliengen - GERMANY Tel.: +49 (0) 7635 827248-0 / info.process@envea.global / www.envea.global...
- Page 2 If you want to communicate with our sensor using our dedicated software, you need to download the latest version on our website and install it. https://www.envea.global/solutions/process-optimization/dahs-software/ It might also be necessary to install drivers, also available on our website.
- Page 3 1st start note 3. MSE 300-DR / -DR2 (NO SCREEN) Our dedicated software must be used to connect to the sensor evaluation unit. Select software language Right click on „Sprache/Language/ Langue“ and select desired language. Connect to sensor Select the correct COM port and connect to the device using the „read device“...
-
Page 4: Table Of Contents
CONTENTS Page Introduction..........3 1.1 Safety . -
Page 5: Introduction
AirSafe 2 is an ambient air dust monitoring device. It is not a safety device. 1.2 Product overview Thousands of electrodynamic sensors from ENVEA Process have proven their worth for measuring dust concentrations in processing systems. AirSafe 2 is a measuring device which can monitor the dust concentration in the ambient air, for example in buildings, production halls, silos, boiler houses and at work stations. -
Page 6: System
1.4 System The AirSafe 2 flow duct measures 500 mm in length and has a diameter of 100 x 100 mm. The integral dust sensor has a 4... 20 mA analog output, a modbus communication port as well as a relay output which switches or trips an alarm if a limit value specified by the customer is exceeded. -
Page 7: Dimensions
2. Dimensions 2.1 Sensor Fig. 1: AirSafe 2 Ex / AirSafe 2 dimensions... -
Page 8: Ex Specifications
Attention: In case of noisy or possibly damaged fan, please unplug the sensor immediatly from any power source and proceed to cleaning. Contact ENVEA Process or your local dealer in case of need. Please keep the sensor clean from dust accumulation. Inside of air channel can be easily cleaned by removing the grid opposite to the fan. -
Page 9: Operation
4. Operation AirSafe 2 measures the dust content in a gas passing trought the sensor using the electrodynamic principle by means of the exchange of charge carriers between the dust particles and the sensor. 4.1 LED indicator Three LED are indicating the state of the Sensor system: •... -
Page 10: One-Button-Setup
4.4 One-Button-Setup 4.4.1 Parameter setup Directly on the sensor the parameter can be changed by using a One-Button-Setup. When Button S1 is pressed all LEDs start blinking on-off simultaneous (1-1-1 to 0-0-0) five times. After this sequence the binary number of the first parameter is lit (0-0-1) for five seconds. -
Page 11: Pc Software
A – Software connection This software is available for download on our website: https://www.envea.global/solutions/process-optimization/product-software/ Please note, that the COM port attributed to the sensor must be between 1 and 16. When the software start in „direct“ Mode there will be a connection established to the AirSafe 2 at Modbus address #2, ModBus address is selectable. - Page 12 B – System Tab This is where the COM port, Baud rate and sensor address are set: ModBus address for direct sensor communication: 2 • ModBus address for DRC communication: 1 • Communications parameters are also available, as well as language (GER/ENG) and the possibility to save and write sensor parameters into a file.
-
Page 13: Basic Parameters
C – Sensor Tab If errors are found in the sensor by internal system tests, they are marked and the sensor and the DRC display sensor error. 4.5.1.1 Basic parameters A default parameter set is established for a new destination system with an empty EEPROM: Parameter Default Meaning... -
Page 14: Autosetup
4.5.1.2 AutoSetup “AutoSetup” starts a search of the alarm value: The sensor searched for the signal level which corresponds to the current dust load. See section sensor manual for a detailed description. 4.5.1.3 Sensor measurement data Dust: the measurement for the dust load ✓... - Page 15 D – Trend Tab The measurement and calculation values of the sensor can be observed here. The sensor’s dust value is always scaled on the left whilst the switch threshold or the relay output, for example, can be visualised on the right. We can show the DUST value on the graph (Dust tick box), the Alarm status (Alarm tick box) and the Threshold level (TRH tick box).
-
Page 16: Dust Pro Software
4.5.2 DUST Pro Software Sensor, Trend ans System tabs remain similar to DUST Base, but it allow communication up to 10 sensors simultaneously. A – List Tab On the left side of the windows: Adr: List of connected sensors with there address. You can choose with sensor you display using the tick boxes. - Page 17 B – Trend Tab In Trend you can display the measurement of the selected sensor. In Trend All all sensors are displayed at the same time.
-
Page 18: Maintenance
The other aim is to prevent the probe becoming encased with accumulated material. No maintenance work is required in the sensor housing or on the field electronics. For any other maintenance, please contact ENVEA Process first and follow our instructions. -
Page 19: Troubleshooting
2. Check whether the green LED is flashing or the yellow LED is lit. This indicates a problem with the relay contact. 3. Check whether the red LED flashes during an active measurement. Error code!! If the sensor is still not supplying signals after these checked, contact our agents or ENVEA Process direct. 6.2 Errors Errors can be seen via the software or via LED‘s status. -
Page 20: Technical Data
5.5 kg Marking DustEx II 3D Ex ic tc IIIC T120 °C Dc ENVEA Process GmbH Gutedelstraße 31 · 79418 Schliengen (Germany) Fon +49 7635 827248-0 · Fax +49 7635 827248-48 · www.envea.global PART OF THE ENVEA GROUP EN 18/11/2021...
