- Page 1 QUICK-START GUIDE (QSG) CAIRNET 3G/4G 6 sensors APRIL 2021 ENVEA RECOMMENDS TO READ ALL THESE INSTRUCTIONS BEFORE POWERING ON AND USING THE EQUIPMENT 111, Bd Robespierre / CS 80004 - 78304 Poissy Cedex 4 - FRANCE Tél : +33(0)1 39 22 38 00 – Fax : +33(0)1 39 65 38 08...
- Page 2 ENVEA cannot be considered liable for direct, indirect or collateral damages due to non-compliant use and/or inappropriate use of the equipment or information contained within this document and our technical manuals.
-
Page 3: Table Of Contents
Figure 2–14 – Connection of the 2-pin connector to the 8-30 VDC IQ-LINK input ............ 22 Figure 2–15 – Fixation of CAIRNET holder and solar panels to the tripod mast ............23 Figure 2–16 – CAIRNET installation on its holder ...................... 24... -
Page 4: Presentation
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited PRESENTATION (1) Sample gas inlet, (2) Air exhaust, (3) antenna Figure 1–1 – CAIRNET box presentation (DO NOT obstruct the sample gas inlet, nor air exhaust). APRIL 2021... - Page 5 Duplication prohibited In standard, each assembly is composed of: – A CAIRNET box (serial number and cloud key – association code for CAIRCLOUD – supplied) including the following internal elements (see Figure 1–2): • An IQ-LINK electronic box (1) providing power supply, measurement recovery and cellular communication (by default, data is sent each 15 minutes).
-
Page 6: Figure 1-2 - Internal Elements Of The Cairnet Box
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited Figure 1–2 – Internal elements of the CAIRNET box Figure 1–3 – On-mast fixation system APRIL 2021... -
Page 7: Figure 1-4 - Iq-Link Top Panel Connections
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited IQ-LINK connectics description: – On the IQ-LINK top panel, the connectors have the following functions : • DC mains power supply (1), 8-30 VDC, 2A. The 2-pin male connector is only supplied with the 12 VDC/ 2.1A waterproof power supply option for outdoor use. -
Page 8: Figure 1-5 - Iq-Link Front Panel
4 – The ON and STATUS LEDs turn off: connection to CAIRCLOUD and data sending. 5 – The ON LED turns again to flashing blue: the data sending cycle is completed, and the CAIRNET operates normally. •... -
Page 9: Installation And Commissioning Procedure
See Figure 1–1. The CAIRNET box is fitted with two hinges used to close and ensure water tightness of the top cover. One of the two hinges opens manually and enables to access inside the CAIRNET (see Figure 2–1, Manual opening hinge). -
Page 10: Screw The External Radio Antenna
The antenna is dismounted before transport, it has to be reassembled during installation. To do this: – Screw the antenna on the lateral side of the CAIRNET box (Figure 2–2). Make sure that the antenna is pointing upwards, with no obstacles around, to ensure an optimum signal. -
Page 11: Free The Iq-Link
Duplication prohibited 2.3. FREE THE IQ-LINK The IQ-LINK box is screwed on two angle brackets fixed to the bottom plate of the CAIRNET: it is necessary to free it to make easier access during the various commissioning operation. To do that: –... -
Page 12: Install The Cairsens
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited 2.5. INSTALL THE CAIRSENS See Figure 2–5 : – Unscrew the 8 hexagonal screws of the sensor holding plate with a 2.5 mm Allen wrench (see (1) of Figure 2–5). Remove the plug(s) where the CAIRSENS will be inserted. -
Page 13: Configuring The Access Point Name (Apn) And Testing The Connection To The Telephone Network
2.6. CONFIGURING THE ACCESS POINT NAME (APN) AND TESTING THE CONNECTION TO THE TELEPHONE NETWORK The parameter setting must be done on a CAIRNET assembly equipped with an IQ-LINK having the antenna correctly mounted and the coaxial cable correctly connected to the IQ-LINK. (See Figure 2–2 and Figure 2–3). - Page 14 1) Open a new web page and connect to the address 192.168.43.1 in the web site address bar : the ENVEA IQ-LINK configuration page is launching. 2) In the INFO section: check that the displayed numbers of CAIRNET serial and CAIRCLOUD key (1) correspond well to the CAIRNET being configured.
-
Page 15: Figure 2-7 - Envea Iq-Link Configuration Interface
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited (1) CAIRNET serial number and CAIRCLOUD key, (2) network operator information, (3) save button, (4) test connect button, (5) results of network connection test. Figure 2–7 – ENVEA IQ-LINK configuration interface APRIL 2021... - Page 16 – Enter the address « https://www.envea.global/envea-connect/ » in the Smartphone/Tablet internet browser, or directly enter “ENVEA connect” in the Play store (Android) or in the App store (iOS), Download the application. – When the application is downloaded: 1 – Touch/click on the icon to start the ENVEA Connect application.
- Page 17 The smartphone/tablet searches for the available Wi-Fi network to connect to. The following message is displayed on the screen: « ENVEA Connect app wants to use a temporary Wi-Fi network to connect to your device». ESA_IQLINK_0000 is the CAIRNET Wi-Fi address.
-
Page 18: Insert The Micro Sim Card In The Iq-Link
The SIM card is to be inserted in the lower part of the IQ-LINK, not shown when assembled inside the CAIRNET. Tilt over the IQ-LINK box or remove it from the CAIRNET. The cable length is sufficient to insert the micro –... -
Page 19: Cairnet Synchronisation With The Caircloud Account
15 minutes of power supply) after the configuration step to be acknowledged in the CAIRCLOUD, before carrying out the synchronization step. The CAIRNETs are identified by their serial number. First, copy the cloud key of each CAIRNET present –... -
Page 20: Powering On Via The Battery And One-Off Re-Load
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited 2.9. POWERING ON VIA THE BATTERY AND ONE-OFF RE-LOAD Connect the battery (3) to the connector (1) of the battery supply board (2), as shown in Figure 2–11. From – this time on, the system is powered up and running. -
Page 21: Solar Panel Connection
IQ-LINK. To do that: – Check that the device is powered off before performing this operation. Free the IQ-LINK electronic box from the CAIRNET to access more easily to the cable connection system – (see § 2.3). -
Page 22: Dc Mains Power Supply
2.11. DC MAINS POWER SUPPLY The CAIRNET can be supplied in continuous via the 8-30 VDC input of the IQ-LINK (see (1) Figure 1–4). This enables to bypass the autonomous power supply board and the battery. In this case, the 12 VDC/ 2.1A waterproof power supply option for outdoor use has to be used. -
Page 23: Fixation On Holder
(see Figure 1–3). – Then, position the CAIRNET on its fixation holder with the hexagonal screws fixed on the rear panel of the boxes to be inserted in the intended-for lock holes (Figure 2–16). For solar panels: –... -
Page 24: Starting On
CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited Figure 2–16 – CAIRNET installation on its holder 2.13. STARTING ON There is no ON/OFF button. As soon as the box is powered on, it starts operating in its normal status. Disconnect it to power off. - Page 25 CAIRNET 3G/4G – 6 SENSORS (QSG) Duplication prohibited Page intentionally left blank APRIL 2021...
