Summary of Contents for Nilfisk-Advance P17-150HD
-
Page 2: When Ordering Parts
DESCRIPTION PLAN Safety Precautions Machine Operation Machine Maintenance & Storage Parts List 5---9 Machine Operation (Chinese) Wiring Diagram WHEN ORDERING PARTS * Use the 7,8 or 9 digit part numbers from the “part number” columns in this parts list. * Specify the model and serial number of the machine. * Use the space below to record the model and the serial Number for future reference. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 2] Before operating machine: !!! This machine must be grounded! Make sure all safety devices are in Grounding provides a path of least resistance place and operate properly. for electrical current. To reduce the risk of electrical shock should machine 3] When using machine:... -
Page 4: Maintenance
Operation of Floor Machine * Read operators manual thoroughly prior to MAINTENANCE operating or servicing this machine. GENERAL USE To keep the machine performing well for many years, please follow the following maintenance 1] Remove any obstructions other procedures. obstacles in the area which is to be cleaned. * Always confirm that the machine is 2] Place the handle in the upright position and unplugged... - Page 6 HANDLE GROUP FOR P17-150HD & P20-150HD PART DESCRIPTION REQ'D 密封端盖 GV40229 COVER GV40228 "O"RING,GEAR SEAT "O"密封圈 尼龙垫片 GV40227 WASHER,NYLON 铝套座 VF40104F SEAT,GEAR 调位齿轮 VF40125B GEAR 防松丝母 M6 VF13502 NUT,LOCK,M6 调位齿杆 VF47052 INSERT 六角螺母 M4 GT13013 NUT M4 拉杆弹簧 VF40121 SPRING LEVELING 拉杆套...
- Page 7 HANDLE GROUP FOR P17-150HD & P20-150HD PART DESCRIPTION REQ'D 双头螺栓垫 VF40140 GASKET 双头螺栓 VF40136 BOLT 水箱 VF40130 TANK 水箱压板 VF40141 CLAMP PLATE 防松丝母 M8 VF13503 NUT,LOCK M8 双头螺栓胶盖 VF99015 RUBBER CAP 双头螺栓胶盖 VF40139 HOSE,SOLUTION 溶液管 BARN HOSE VF40132 螺母 M14...
- Page 9 BASE GROUP FOR P17-150HD & P20-150HD PART DESCRIP TION REQ'D 内六角螺钉 M8X60 GT13016 SCREW M8X60 铝套座支架 VF72202 MOUNTING BASE,GEAR 内六角螺钉 M6X35 GT13080 SCREW M6X35 WASHER,PLAIN φ8 平垫圈 φ8 VF13514 防松丝母 M8 VF13503 NUT,LOCK,M8 WASHER,PLAIN φ6 平垫圈 φ6 GT13030 防松丝母 M6...
- Page 10 安全预防 维护与保养 本机必须接地！ 为使本机始终保持良好的性能， 请遵循以下程 为减少机器因故障而引起的触电危险， 本机电 序保养本机 源线插头带有一接地插脚， 任何情况下不得去 进行任何维护、保养工作前，必须确保 除该插脚。 机器已断开电源 本机仅作商业用途， 并限于户内使用。 务必使 1、机器一经使用完毕，立即拔下电源插头； 用推荐的附件， 操作者应阅读， 理解并掌握以 2、取下针座或刷子； 下安全预防措施： 存放机器时，切勿忘记取下针座或刷子 1、以下情况不得操作本机： 3、用中性清洁剂清洁机器； 未经培训取得相应资格； 4、检查机器电源线有无破损，如有应立即进 未仔细阅读和理解操作手册； 行更换； 在易燃易爆场所； 为避免危险，若电源线破损，必须联系 电源线或插头损坏； 当地售后服务部进行更换； 机器存在问题不适合操作； 5、每月用防水润滑剂润滑轮子、轴； 在户外时； 6、 检查机器有否遗失螺母、 螺栓并进行更换； 在水中； 7、机器在粉尘的场所使用后，应取下电机顶...
