A-2 / ENGLISH TABLE OF CONTENTS page Introduction ... A-2 Cautions and Warnings ... A-3 Consignes de prudence et de sécurité ... A-4 Know Your Machine ... A-5 Control Panel ... A-6 Prepare the Machine for Use Install the Batteries ... A-7 Install the Brushes ...
CAUTIONS AND WARNINGS SYMBOLS Nilfi sk-Advance uses the symbols below to signal potentially dangerous conditions. Always read this information carefully and take the necessary steps to protect personnel and property. DANGER! Is used to warn of immediate hazards that will cause severe personal injury or death. WARNING! Is used to call attention to a situation that could cause severe personal injury.
A-4 / ENGLISH CONSIGNES DE PRUDENCE ET DE SÉCURITÉ SYMBOLES Les symboles reproduits ci-dessous sont utilisés pour attirer l’attention de l’opérateur sur des situations dangereuses. Il est donc conseillé de lire attentivement ces indications et de prendre les mesures adéquates en vue de protéger le personnel et le matériel. DANGER! Ce symbole est utilisé...
KNOW YOUR MACHINE As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item shown on these pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in the text. NOTE: Refer to the service manual for detailed explanations of each item illustrated on the next 2 pages.
DESCRIPTION OF THE BATTERY CONDITION INDICATORS The battery condition indicator (K) consists of three lights, a green, a yellow, and a red. The voltage indication will change based on the cutoff level (standard or alternate) selected in the control unit. The battery voltage ranges for the various indications are listed below: Standard Green 34.00+...
A-8 / ENGLISH INSTALL THE BRUSHES (DISC SYSTEM) CAUTION ! Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels. Make sure the Key Switch (J) is off (O). To access the brushes, remove both side skirt assemblies. Note: The skirts are held in place by a two large Knobs, loosen these knobs and slide the skirt assemblies off of the Scrub Deck.
INSTALL THE SQUEEGEE Make sure the Squeegee (19) is up (O) and the Key Switch (J) is off (O). Hold the squeegee tool so that the curved ends point forward, then slide the squeegee tool onto the Mount (A) (See Figure 2). Hand tighten the Thumb Nuts (B) and then connect the vacuum hose to the Squeegee Tube (C) (vacuum hose should loop to the right).
A-10 / ENGLISH DETERGENT SYSTEM PREPARATION AND USE (AXP/EDS MODELS ONLY) COMMON INSTRUCTIONS: The system should be purged of previous detergent when switching to a different detergent. SERVICE NOTE: Move machine over fl oor drain before purging because a small amount of detergent will be dispensed in the process. To Purge When Changing Chemicals: Disconnect and remove the detergent cartridge.
Page 11
ENGLISH / A-11 DETERGENT SYSTEM PREPARATION AND USE (AXP/EDS MODELS ONLY) FRONT revised 3/06 FORM NO. 56041554 - Advenger , Advenger AXP / BR 600S series - A-11 ™ ™...
A-12 / ENGLISH OPERATING THE MACHINE WARNING ! Be sure you understand the operator controls and their functions. While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. Clean only while ascending (driving up) the ramp. To Scrub...
AFTER USE When fi nished scrubbing, press the Scrub Off Switch (B) twice, this will automatically raise, retract and stop all the machine systems (brush, squeegee, vacuum, solution and detergent (AXP/EDS models)). Then drive the machine to a service area for daily maintenance and review of other needed service up keep.
A-14 / ENGLISH CHARGING THE BATTERIES Charge the batteries each time the machine is used, or whenever the Battery Condition Meter (K) is showing a yellow , red or fl ashing red indicator light(s). To Charge the Batteries... Depress the Battery Disconnect (13). Open the Battery Compartment Cover (16) to provide proper ventilation.
SQUEEGEE MAINTENANCE If the squeegee leaves narrow streaks or water, the blades may be dirty or damaged. Remove the squeegee, rinse it under warm water and inspect the blades. Reverse or replace the blades if they are cut, torn, wavy or worn. To Reverse or Replace the Rear Squeegee Wiping Blade...
A-16 / ENGLISH SIDE SKIRT MAINTENANCE (DISC SYSTEM) The side skirt’s function is to channel the waste water to the squeegee, helping contain the water within the machines cleaning path. During normal use the blades will wear in time. The operator will notice a small amount of water leaking out underneath the side skirts. A height adjustment can easily be made to lower the blades so that all the water can be pick-up by the squeegee.
Page 17
ENGLISH / A-17 SIDE SKIRT MAINTENANCE (CYLINDRICAL SYSTEM) The side skirts function is to channel the waste water to the squeegee, helping contain the water within the machines cleaning path. During normal use the blades will wear in time. The operator will notice a small amount of water leaking out underneath the side skirts. Skirt height adjustment is automatic on this system.
A-18 / ENGLISH GENERAL MACHINE TROUBLESHOOTING Problem Possible Cause Poor water pick-up Worn or torn squeegee blades Squeegee out of adjustment Recovery tank full Recovery tank drain hose leak Recovery tank cover gasket leak Debris caught in squeegee Vacuum hose clogged Using too much solution Foam fi...
Page 19
TECHNICAL SPECIFICATIONS (as installed and tested on the unit) Model Model No. Voltage, Batteries Battery Capacity Protection Grade Sound Pressure Level (IEC 60704-1) dB(A)/20μPa Gross Weight lbs / kg Vibrations at the Hand Controls (ISO 5349-1) Vibrations at the Seat (EN 1032) Gradeability Transport Cleaning...
Page 20
B-2 / ESPAÑOL ÍNDICE página Introducción ... B-2 Precauciones y advertencias ... B-3 Conozca su máquina ... B-4 Panel de control ... B-5 Preparación de la máquina para el uso Instalación de las baterías ... B-6 Instalación de los cepillos ... B-7 Instalación de la boquilla ...
PRECAUCIONES Y ADVERTENCIAS SÍMBOLOS Nilfi sk-Advance utiliza los símbolos que aparecen a continuación para indicar situaciones potencialmente peligrosas. Lea siempre con atención esta información y tome las medidas necesarias para la protección del personal y los objetos. ¡PELIGRO! Se utiliza para advertir de peligros inmediatos que pueden producir graves daños personales o la muerte. ¡ADVERTENCIA! Se utiliza para llamar la atención sobre una situación que puede causar graves daños personales.
B-4 / ESPAÑOL CONOZCA SU MÁQUINA A lo largo de este manual encontrará números o letras en negrita entre paréntesis – por ejemplo: (2). Estos números se refi eren a un objeto que se muestra en dicha página, a menos que se indique lo contrario. Consulte estas páginas siempre que lo necesite para localizar los elementos citados en el texto. NOTA: Consulte el manual de servicio para obtener explicaciones más detalladas de cada objeto ilustrado en las siguientes 2 páginas.
PANEL DE CONTROL Indicador de apagado del fregado Interruptor de apagado del fregado Indicador de disminución de la presión de fregado Interruptor de disminución de la presión de fregado Indicador de aumento de la presión de fregado Interruptor de aumento de la presión de fregado Pantalla de presión de fregado/cronómetro Indicador del interruptor de la vara Interruptor de la vara...
B-6 / ESPAÑOL DESCRIPCIÓN DE LOS INDICADORES DE SITUACIÓN DE LAS BATERÍAS El indicador de situación de las baterías (K) consta de tres luces: una verde, una amarilla y una roja. La indicación de la tensión cambiará en función del nivel máximo (estándar o alternativo) seleccionado en la unidad de control.
INSTALACIÓN DE LOS CEPILLOS (SISTEMA DE DISCO) ¡PRECAUCIÓN! Apague el interruptor de llave (O) y quite la llave antes de cambiar los cepillos y antes de abrir cualquiera de los paneles de acceso. Asegúrese de que está apagado (O) el conmutador de llave (J). Para llegar a los cepillos, retire los conjuntos de faldillas de los dos lados. Nota: Las faldillas está sujetas a cada lado con dos botones grandes, afl...
B-8 / ESPAÑOL REPARACIÓN Y USO DEL SISTEMA DE DETERGENTE (AXP/EDS) INSTRUCCIONES COMUNES: Elimine del sistema el detergente anteriormente utilizado antes de cambiar a un detergente diferente. NOTA DE SERVICIO: Desplace la máquina sobre un punto de drenaje en el suelo antes de eliminar el detergente porque saldrá una pequeña cantidad durante el proceso.
Page 27
ESPAÑOL / B-9 REPARACIÓN Y USO DEL SISTEMA DE DETERGENTE (AXP/EDS) FRONT revised 3/06 FORM NO. 56041554 - Advenger , Advenger AXP / BR 600S series - B-9 ™ ™...
B-10 / ESPAÑOL MANEJO DE LA MÁQUINA ¡ADVERTENCIA! Asegúrese de que comprende los controles del operador y sus funciones. Si se encuentra sobre una rampa o inclinación, evite las paradas bruscas cuando lleve carga. No tome las curvas bruscamente. Utilice una velocidad lenta si va cuesta abajo. Limpie sólo yendo cuesta arriba. Para fregar...
DESPUÉS DE LA UTILIZACIÓN Cuando acabe de fregar, pulse el interruptor de apagado del fregado (B) dos veces; esto producirá la elevación, retracción y detención automática de todos los sistemas de la máquina (cepillo, boquilla, aspiración, solución y detergente (modelos AXP/EDS)). A continuación conduzca la máquina a la zona de mantenimiento para el mantenimiento diario y la revisión de otros servicios necesarios.
B-12 / ESPAÑOL RECARGA DE BATERÍAS Recargue las baterías cada vez que se use la máquina o cuando el indicador de la situación de las baterías (K) presente una luz indicadora amarilla, roja o roja intermitente. Para cargar las baterías... Pulse la desconexión de las baterías (13).
MANTENIMIENTO DE LA BOQUILLA Si la boquilla deja bandas estrechas de agua, puede que las cuchillas estén sucias o dañadas. Retire la boquilla, enjuáguela con agua tibia e inspeccione las cuchillas. Sustituya o invierta las cuchillas si están cortadas, rasgadas, onduladas o gastadas. Para invertir o sustituir la cuchilla secadora de la boquilla trasera...
B-14 / ESPAÑOL MANTENIMIENTO DE LA FALDILLA LATERAL (SISTEMA DE DISCOS) La función de las faldillas laterales es canalizar el agua residual hasta la boquilla, lo que ayuda a mantener el agua dentro de la trayectoria de limpieza de la máquina. Es normal que las cuchillas se vayan desgastando con el tiempo. El operador verá que una pequeña cantidad de agua sale por debajo de las faldillas laterales.
Page 33
ESPAÑOL / B-15 MANTENIMIENTO DE LA FALDILLA LATERAL (SISTEMA CILÍNDRICO) La función de las faldillas laterales es canalizar el agua residual hasta la boquilla, lo que ayuda a mantener el agua dentro de la trayectoria de limpieza de la máquina. Es normal que las cuchillas se vayan desgastando con el tiempo. El operador verá que una pequeña cantidad de agua sale por debajo de las faldillas laterales.
Page 34
B-16 / ESPAÑOL SOLUCIÓN DE PROBLEMAS GENERALES DE LA MÁQUINA Problema Posible causa Recogida escasa del agua Cuchillas de la boquilla gastadas o Desgarradas Boquilla mal ajustada en toda su anchura Depósito de recuperación lleno Fuga en la tubería de drenaje del depósito de recuperación Fuga en la junta de la tapa del tanque de recuperación...
Page 35
ESPECIFICACIONES TÉCNICAS (según la instalación y comprobaciones de la unidad) Modelo Nº Modelo Voltaje, baterías Capacidad de baterías Grado de protección Nivel de presión sonora dB(A)/20μPa (IEC 60704-1) Peso bruto lbs / kg Vibración en los controles manuales (ISO 5349-1) Vibración en el asiento (EN 1032) Capacidad ascendente Transporte...
Page 38
_____________________________________________________ TYPE: BR600S, BR600SC, BR700S, BR700SC, BR800S, BR800SC BR600S EDS, BR600SC EDS, BR700S EDS, BR700SC EDS, BR800S EDS, BR800SC EDS EU Overensstemmelseserklæring Batteridreven gulvaskemaskine Maskinen er fremstillet i overensstemmelse med følgende direktiver: Maskindirektiv: 98/37/EØF EMC-direktiv: 89/336/EØF 92/31/EØF 93/68/EØF 98/13/EOF Lavspændingsdirektiv: 73/23/EØF 93/68/EØF Harmoniserede standarder: EN 60 335-2-72 EU Överensstämmelseförsäkran Batteri-Skurmaskin...
