- Page 1 Mirrored Core Cabinet 2 Door 403/9448 50cm 13cm 60cm Issue 2 - 03/16/20...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:03456 400800 Please check you have all the panels listed below Left side panel x 1 3 Back rail x 1 Right side panel x 1 5 Bottom panel x 1 6 Adjustable shelf x 2 4 Top panel x 1 7 Back panel x 2...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required. Hinge x 4 Locking pin x 4 Locking nut x 4 Φ4 x 12mm Screw x 24...
- Page 5 Assembly Instructions Step 1 Assembling side panels NOTE:It would be useful to ask someone to help you at this stage. Screw 4 x locking pin into left side panel and right side panel Insert 6 x wooden dowel to right side panel as shown.
- Page 6 Assembly Instructions Step 2 Fixing om the wall NOTE:It would be useful to ask someone to help you at this stage. Use 45mm screw and wall plug to fix the unit on the wall as shown. Step 3 Assembling adjustable panel NOTE:It would be useful to ask someone to help you at this stage.
- Page 7 Assembly Instructions Step 8 Step 4 Assembling door panel NOTE:It would be useful to ask someone to help you at this stage. Use 4 x screw to fix 2 x hinge onto door panel Carefully attach door panel to the unit by fixing hinge onto side panel with 12mm screws Adjust the door up or down, left or right, in or out if needed as shown:...
- Page 8 A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
