Summary of Contents for Argos Home Le Marais 419/6350

  • Page 1 Le Marais Undersink Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 3 - 05/28/21...
  • Page 2: Product Details

    Safety and Care Advice Product Details 419/6350 Le Marais Undersink Grey 944/5989 Le Marais Undersink White IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Keep children and animals Assemble the item as close We do not away from the work area, small recommend the room) as possible.
  • Page 3 Fittings Handle x 2 Locking Nut x 8 Metal Dowel x 8 10mm Screw x 14 14mm Screw x24 18 mm Bolt x 2 Hanger Bracket x 2 Metal Support x 4 14mm Screw x 2 Hardware Hinge ×4...
  • Page 4: Tools Required

    Tools required Phillips screwdriver Ruler/tape (small & medium) measure Phillips screwdriver Eye protection (small & medium) (when using a hammer or glue) Large hammer Power Drill Pencil Drill Heads...
  • Page 5 Panels Bottom panel Adjustable shelf Top panel (600x 330mm) (538 x 294mm) (600 x 330mm) Right door panel Left door panel Side panel x 2 (505 x 267mm) (505 x 267mm) (510 x 315mm) Back panel x2 (530 x 165mm)
  • Page 6 Handle x 2 Locking Nut x 8 Metal Dowel x 8 Metal Dowel x 8 14mm Screw x 2 10mm Screw x 14 14mm Screw x24 18 mm Bolt x 2 Hanger Bracket x 2 Metal Support x 4 14mm Screw x 2 Hanger Bracket x 2...
  • Page 7 Locking Nut x 4 Locking Nut x 4...
  • Page 8 10mm Screw x 14 Turn Product Metal Support x 4...
  • Page 9 14mm Screw x 8 Hinge...
  • Page 10 14mm Screw x 16 18mm Bolt x 2 Handle x 2...
  • Page 11 WARNING! Wall fixings are not supplied. Please refer to A Guide To Wall Mounting & Fixings, page 12.
  • Page 12: A Guide To Wall Mounting & Fixings

    A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.

This manual is also suitable for:

Le marais 944/5989
