ASSEMBLY INSTRUCTION FOR ACME FURNITURE

Thank you for purchasing the quality product. Be sure to check all packing material carefully for small parts which

may have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware.

Compare with all parts are present. If any part(s) are missing or damaged, please contact your local furniture dealer.

For efﬁcient and speedy service, please indicate the model number and code letter of part(s) needed.

***Do not fully tighten screws until fully assembled.***

MODEL#97777

SHOE CABINET

DIMENSIONS

Width - 46.06"

Depth - 15.75"

Height - 46.93"

Need help?

Do you have a question about the 97777 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION FOR ACME FURNITURE MODEL#97777 Thank you for purchasing the quality product. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware.
Page 2: Parts List
97777 PARTS LIST Right door Top support Left side Right side Layer Back support Bottom Back Left door...
Page 3: Hardware List
HARDWARE LIST T-head screw Cam bolt 7*35*12.5mm 4*12mm Floor protector 24mm*1/4*12mm Cam lock 15*12mm Vent cap Dowel 8*30mm 60mm*66mm*3mm Coarse screw 7*11*50mm Glue Shelf pin 4.9*16mm Allen wrench Door wheel Sticker #6*7/8" Wood screw Fixative plate Wood screw 3*19mm Foot Support foot Attention Some number parts listed on the instruction sheet may not be in parts bag as they may already be assembled.
Page 4 ASSEMBLY INSTRUCTIONS Step 1.
Page 5 ASSEMBLY INSTRUCTIONS Step 2.
Page 6 ASSEMBLY INSTRUCTIONS Step 3. Insert in as arrow direction to specify...
Page 7 ASSEMBLY INSTRUCTIONS Step 4.
Page 8 ASSEMBLY INSTRUCTIONS Step 5.
Page 9 ASSEMBLY INSTRUCTIONS Step 6.
Page 10 ASSEMBLY INSTRUCTIONS Step 7. ASSEMBLY IS COMPLETED. Make sure the product is rested on a ﬂat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
