Hygena Genoa Slatted Sideboard
Assembly Instructions
481/2380D
- Please keep for future reference
Dimensions
Width - 120cm
Depth - 40cm
Height - 69cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 16/09/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Hygena Genoa 481/2380D
Summary of Contents for Argos Hygena Genoa 481/2380D
- Page 1 Hygena Genoa Slatted Sideboard Assembly Instructions 481/2380D - Please keep for future reference Dimensions Width - 120cm Depth - 40cm Height - 69cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 16/09/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 &... - Page 3 Components - Panels Please check you have all the panels listed below Foot x 5 Top panel Bottom panel (60 x 60 mm) (1200 x 390mm) (1200 x 390 mm) Right side panel Divider Left side panel (524 x 389mm) (524 x 325mm) (524 x 389mm) Adjustable shelf x 4...
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Lay Bottom Panel its long taped edge on a flat soft surface. Untaped edge. Push Large wood dowels into indicated holes in Bottom panel. Push Legs onto the wood dowels in Bottom panels and fasten using 50mm Screws Step 2 Untaped edge.
- Page 6 Assembly Instructions Step 3 Screw 6 Metal dowels into the threaded holes in Top Panel shown. Step 4 Insert Small wood dowels into the middle holes in dowels and wood Side panels and Divider. dowels enter corresponding holes. Firmly push the Top Panel onto the ends of the panels...
- Page 7 Assembly Instructions Step 6 Unfold Rear Panel Secure the Rear Panel into the rear edges of side panels, top panel and bottom panel Tape. using 14mm Screws Note - make sure cabinet is square before securing rear panel in place. Measure on the back across the 2 diagonals to make sure cabinet is...
- Page 8 Assembly Instructions Step 8 2 people needed for this step. Make sure the pin in the top lock in the Door is down, if not, push it down until it locks. Insert the bottom rollers of Door in the inner groove in the bottom panel, holding the door and push the top edge to...
