Hygena Cubic Wood Glass Low SB/TV Unit
Assembly Instructions
482/0688D
- Please keep for future reference
Dimensions
Width - 120cm
Depth - 38cm
Height - 61.8cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 16/09/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 482/0688D
Summary of Contents for Argos 482/0688D
- Page 1 Hygena Cubic Wood Glass Low SB/TV Unit Assembly Instructions 482/0688D - Please keep for future reference Dimensions Width - 120cm Depth - 38cm Height - 61.8cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 &... - Page 3 Components - Panels Please check you have all the panels listed below Left side panel Right side panel Top panel (376 x 600 mm) (376 x 600mm) (1200 x 380 mm) Right divider Front top rail Left divider (600 x 359mm) (1078 x 60mm) (600 x 359mm) Bottom panel x 2...
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Screw 8 Metal dowels into the threaded holes in the Left and Right side panels and Left and Right divider as shown. Insert Wood dowels into the indicated holes. Step 2 Firmly push Right side panel and Right divider onto the ends...
- Page 6 Assembly Instructions Step 3 Insert the 8 Metal cams into the 8 holes on the Bottom panels so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards end of panels (as shown). Then, using a Philips Screwdriver, screw all Metal cams...
- Page 7 Assembly Instructions Step 5 Insert the 2 Metal cams into the 2 holes on the Rear rail so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards end of rail (as shown). Then, using a Philips Screwdriver, screw all Metal cams...
- Page 8 Assembly Instructions Step 7 Insert the 8 Metal cams into the 8 holes on the side panels and dividers so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards metal dowels. Then, using a Philips Screwdriver, screw all Metal cams clockwise until they are...
- Page 9 Assembly Instructions Step 9 Insert the 12 Metal cams into the 12 holes on the side panels, dividers and front rail so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards metal dowels. Then, using a Philips Screwdriver, screw all Metal cams...
- Page 10 Assembly Instructions Step 11 Push the top Glass shelf into the Shelf holders and secure with the screws by turning clockwise as shown. Repeat this step to assemble the other two glass shelves. Peel off the cover of the Foot pads , attach to the bottom edges of side panels and dividers...
- Page 11 Assembly Instructions Step 13 Locate the Right side door onto the Right side panel , screw the Hinges to the pre-drilled holes, using 14mm Screws shown. Step 14 Push 4 Shelf Pins into each side of the side panels and dividers at desired height.
- Page 12 Assembly Instructions Step 15 Firmly push Corner blocks into the grooves in the coners of rear panels on the rear side as shown, secure with 14mm Screws Cover the visible cam holes with Cover pads Step 16 Adjust the door: To move doors in or out: loosen screw shown and move doors...
