an ISO 9001:2008 Registered Company
1967-68 Chevrolet Camaro
without Factory Air
Control Panel Conversion Kit
475168
18865 Goll St. San Antonio, TX 78266
Phone: 210-654-7171
Fax: 210-654-3113
www.vintageair.com
905168 REV G 4/13/15, PG 1 OF 17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1967-68 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vintage Air 1967-68

  • Page 1: Cover

    ISO 9001:2008 Registered Company 1967-68 Chevrolet Camaro without Factory Air Control Panel Conversion Kit 475168 18865 Goll St. San Antonio, TX 78266 Phone: 210-654-7171 Fax: 210-654-3113 www.vintageair.com 905168 REV G 4/13/15, PG 1 OF 17...
  • Page 2: Table Of Contents

    Table of Contents www.vintageair.com Thank you for purchasing this control panel kit from Vintage Air. When installing these components as part of a complete SureFit™ system, Vintage Air recommends working from front to back on the vehicle, installing the condenser kit, hose kit, and compressor first, followed by the wiring, evaporator, and finally the control panel.
  • Page 3: Packing List/Parts Disclaimer

    Label Backing ** Before beginning installation, open all packages and check contents of shipment. Please report any shortages directly to Vintage Air within 15 days. After 15 days, Vintage Air will not be responsible for missing or damaged items. DASH NOTE: Images may not depict actual parts and quantities.
  • Page 4: Removing Oem Control Panel, Placard Installation

    Removing OEM Control Panel www.vintageair.com Perform the Following: Remove (4) OEM screws from the dash bezel, under the dash (retain) (See Figure 1, below). Remove the OEM control panel from the dash (retain). Disconnect the cables and wires from the back side of the OEM controls (discard).
  • Page 5: Placard Installation (Cont.)

    Placard Installation (Cont.) www.vintageair.com Locate the OEM placard. Turn the placard over, and apply the white backing labels to the back side of the OEM placard as shown in Figure 3a, below. NOTE: These white stickers are applied to the back side of the control panel placard to balance the amount of light across the face of the control panel.
  • Page 6: Cable Converter Assembly Modification, Cable Converter Assembly Mounting Clamp Installation

    Cable Converter Assembly Modification www.vintageair.com Locate the (3) cable converter assemblies. Using a pair of wire cutters, cut the cable converter actuator rods as shown in Figure 4, below. Off/Hi Lever Cut at Each Side Cut at 2nd Hole of Hole as Shown (Remove Shaded Portion) Cold/Hot Lever Cable Converter...
  • Page 7: Dash/Floor/Defrost Cable Converter Assembly Installation

    Dash/Floor/Defrost Cable Converter Assembly Installation www.vintageair.com Turn control panel over, with bottom side facing up. Install the cable converter assembly onto the Dash/Floor/Defrost lever (See Figure 6, below). Install the cable converter push rod onto the OEM cable mounting stud on the lever. Secure the cable converter assembly onto the OEM control panel using the OEM screw in the OEM cable clamp mounting location (See Figure 6, below).
  • Page 8: Dash/Floor/Defrost Control Harness

    Dash/Floor/Defrost Control Harness www.vintageair.com Remove OEM fan switch actuator stud (See Figure 7 and photos, below). NOTE: Fan switch actuator stud removal is required to allow clearance for duct hoses. Failure to remove the stud will result in a punctured duct hose. Locate the control panel wiring harness, and plug the corresponding wire into the correct cable converter assembly as shown in Figure 7, below.
  • Page 9: Cold/Hot Cable Converter Assembly Installation, Cold/Hot Control Harness

    Cold/Hot Cable Converter Assembly & Control Harness Installation www.vintageair.com Install the cable converter assembly onto the Cold/Hot lever. Install the cable converter push rod onto the OEM cable mounting stud on the lever. Secure the cable converter assembly onto the OEM control panel using the OEM screw in the OEM cable clamp mounting location (See Figure 9, below).
  • Page 10: Cold/Hot Control Harness (Cont.), Off/Hi Cable Converter Assembly Installation

    Cold/Hot Control Harness (Cont.) www.vintageair.com Once the wires are correctly plugged into the cable converter assembly, secure the wires to the cable converter assembly using the supplied tie wraps. The tie wrap must be located between the end of the wire jacket and the step in the cable converter housing, forcing a bend in each wire as it passes over the step in the cable converter housing.
  • Page 11: Off/Hi Control Harness

    Off/Hi Control Harness www.vintageair.com Locate the control panel wiring harness, and plug the corresponding wire into the correct cable converter assembly (See Figure 13, below). Once the wires are correctly plugged into the cable converter assembly, secure the wires to the cable converter assembly using the supplied tie wraps.
  • Page 12: Final Steps

    Final Steps www.vintageair.com Using the supplied tie wraps, tie the wires to the control panel. Confirm that wires are secured and do not interfere with lever operation or cable converter assembly. Install control panel into dash using OEM screws. To ease installation, rotate control panel slightly and pass the cable converter assemblies through the dash opening first.
  • Page 13: Control Panel Calibration Procedure

    Calibration Procedure On Vintage Air Gen IV systems using factory controls, it is necessary to calibrate the system to your specific control panel. This procedure ensures that the stroke of your control panel levers or knobs is translated into precise control of the fan speed, temperature blend and mode door position.
  • Page 14: Control Panel Calibration Procedure (Cont.)

    Control Panel www.vintageair.com Calibration Procedure (Cont.) 1. Turn on the ignition switch (Do not start the engine). 2. Move the control levers/knobs to the position shown. DASH 3. Connect the white jumper wire to the gray program wire. Wait for the blower speed to change (Approximately 5 seconds).
  • Page 15: Wiring Diagram

    Wiring Diagram www.vintageair.com 232007-VUR AC ANNUNCIATOR BACKLIGHT POS BACKLIGHT NEG 5V-SW WHT/RED TEMP WIPER WHT/YEL MODE WIPER WHT/GRN FAN WIPER PRE-WIRED VIEWED FROM WIRE SIDE 232002-VUA GEN IV ECU GEN IV WIRING DIAGRAM (IF USED) REV D, 5/6/2014 TEMP MODE PROGRAM * DASH LAMP (IF USED)
  • Page 16: Operation Of Controls

    Operation of Controls www.vintageair.com On Gen IV systems with three lever/knob controls, the temperature control toggles between heat and A/C operations. To activate A/C, move the temperature lever/knob all the way to cold and then back it off to the desired vent temperature.
  • Page 18: Packing List

    Packing List: (475168) Control Panel Conversion Kit 1967-68 Chevrolet Camaro www.vintageair.com without Factory Air Qty. Part No. Description 484168 Label, Control Panel Mode 112002-SUA Cable Converter Assembly 232002-VUA Control Harness, Gen IV Universal 65976-VUE Push-on Ring, 3/16” 491010-VUR Clamp, Cable Converter 21301-VUP Tie Wrap, 4”...
