- Page 1 ISO 9001:2008 Registered Company INSTALLATION INSTRUCTIONS FOR 1956 FORD F-100 TRUCK HEAT/COOL/DEFROST 75456-LFZ-A 18865 GOLL ST. - SAN ANTONIO, TX. - 78266 - ph.210-654-7171 - fax 210-654-3113 905456-LFZ-A REV E 03/05/14, 56 FORD PICK UP INSTRUCTIONS PG 1 OF 19...
-
Page 2: Table Of Contents
1956 F-100 FORD TRUCK w/ H/C/D Table of Contents PAGES COVER TABLE OF CONTENTS PACKING LIST INFORMATION PAGE PASSENGER COMPARTMENT CONDENSER ASSEMBLY CONDENSER HARDLINES FIGURE 3 CONDENSER HARDLINE, COMPRESSOR BRKT. & EVAP . PREPARATION FIGURE 4 EVAPORATOR INSTALLATION FINAL STEPS FIGURE 5 &... - Page 3 ACCESSORY KIT ** BEFORE BEGINNING INSTALLATION, OPEN ALL PACKAGES AND CHECK CONTENTS OF SHIPMENT. PLEASE REPORT ANY SHORTAGES DIRECTLY TO VINTAGE AIR WITHIN 15 DAYS. AFTER 15 DAYS, VINTAGE AIR WILL NOT BE RESPONSIBLE FOR MISSING OR DAMAGED ITEMS. EVAP. SUB CASE...
- Page 4 32000-VUF - CLUTCH FAN THIS KIT DOES NOT CONTAIN HEATER HOSE. YOU MUST PURCHASE 8 FEET OF 5/8" DIA. HEATER HOSE FROM VINTAGE AIR (31800-VUD) OR FROM YOUR LOCAL PARTS RETAILER. SAFETY SWITCHES: A COMPRESSOR SAFETY SWITCH MUST BE INSTALLED ON EVERY A/C SYSTEM. A BINARY SWITCH (PART# 24679-VUS) DISENGAGES THE COMPRESSOR CLUTCH IN CASE OF EXTREME LOW PRESSURE CONDITIONS (REFRIGERANT LOSS) OR EXCESSIVELY HIGH HEAD PRESSURE (406 PSI.) TO PREVENT...
-
Page 5: Passenger Compartment
1956 F-100 FORD TRUCK w/ H/C/D INSTALLATION INSTRUCTIONS FOR 1956 F-100 FORD PICKUP WITH HEAT/COOL/DEFROST BEFORE STARTING THE AIR CONDITIONER INSTALLATION, CHECK FOR NOTE PROPER OPERATION OF ALL COMPONENTS (RADIO, LIGHTS, WIPERS, ETC.). STUDY THE INSTRUCTIONS, ILLUSTRATIONS AND DIAGRAMS. PASSENGER COMPARTMENT 1. - Page 6 1956 F-100 FORD TRUCK w/ H/C/D CONDENSER INSTALLATION 1. REMOVE GRILL ASSEMBLY. 2. LOOSEN THE TWO 3/8" O.E.M. MOUNTING BOLTS AS SHOWN IN FIGURE 3, PAGE 7. 3. POSITION CONDENSER ON CORE SUPPORT AS SHOWN IN FIGURE 3, PAGE 7. 4.
-
Page 7: Condenser Hardlines
1956 F-100 FORD TRUCK w/ H/C/D CONDENSER HARDLINES IF THE COMPRESSOR IS MOUNTED ON THE DRIVER SIDE OF THE ENGINE, PROCEED WITH THE INSTRUCTIONS TITLED: CONDENSER HARDLINES (DRIVER SIDE COMPRESSOR MOUNTING). IF THE COMPRESSOR IS MOUNTED ON THE PASSENGER SIDE OF THE ENGINE, PROCEED WITH THE INSTRUCTIONS TITLED: CONDENSER HARDLINES (PASSENGER SIDE COMPRESSOR MOUNTING). -
Page 8: Figure 4
1956 F-100 FORD TRUCK w/ H/C/D CONDENSER HARDLINES (PASSENGER S IDE COMPRESSOR MOUNTING): 1. LOCATE THE 1-1/4" GROMMET WITH THE TWO HOLES. 2. INSTALL THIS GROMMET IN THE 1-1/4" HOLE (PREVIOUSLY DRILLED) ON THE PASSENGER SIDE OF THE CORE SUPPORT. 3. -
Page 9: Evaporator Installation
1956 F-100 FORD TRUCK w/ H/C/D EVAPORATOR INSTALLATION 1. PLACE EVAPORATOR UNDER DASH ON PASSENGER SIDE WITH THE FEEDER TUBE OUTLETS POINTED TOWARD THE FIREWALL. 2. INSTALL BINARY SAFETY SWITCH AS SHOWN ON PAGE 11. 3. POSITION THE EVAPORATOR BEHIND DASH BY TILTING THE UNIT APPROXIMATELY 45° TOWARD YOURSELF, WITH THE TUBES FACING THE FIREWALL. ROTATE THE EVAPORATOR AWAY FROM YOU, SO THAT THE TUBE OPENINGS ARE POINTING INTO THE ENGINE COMPARTMENT THROUGH THE O.E.M. -
Page 10: Final Steps
(INSTALLED WARRANTY. CHECK COMPLETE A/C ASSEMBLY FOR PROPER OPERATION. AT FACTORY) VINTAGE AIR RECOMMENDS THAT ALL A/C SYSTEMS BE SERVICED BY A CERTIFIED AUTOMOTIVE AIR CONDITIONING TECHNICIAN ONLY. SEE INSIDE COVER FOR SERVICE INFORMATION. •START ENGINE AND RUN UNTIL NORMAL OPERATING TEMPERATURE IS REACHED. - Page 11 1956 F-100 FORD TRUCK w/ H/C/D 2-1/2" LENGTH HEATER HOSE (CONNECT TO HEATER CONTROL VALVE) INSTALL BINARY EXPANSION SAFETY VALVE SWITCH 2-1/2" LENGTH HEATER HOSE 35057-LFG 35056-LFG 35059-LFG 35058-LFG NOTE: ARROWS INDICATE DIRECTION OF REFRIGERANT FLOW DETAIL 1/2" 5/8" 3/8" FIGURE 7 FIGURE 7 A 905456-LFZ-A REV E 03/05/14, 56 FORD PICK UP INSTRUCTIONS PG 11 OF 19...
- Page 12 1956 F-100 FORD TRUCK w/ H/C/D PASSENGER SIDE CORE SUPPORT DRIVER SIDE CORE SUPPORT RADIATOR RADIATOR BOLT BOLT (#8 DISCHARGE LINE) (#6 DRIER TO EVAPORATOR LINE) 35015-LFG 35013-LFG FIGURE 8 DRIVER’S SIDE COMPRESSOR MOUNT LINE ROUTING RADIATOR BOLT PASSENGER SIDE COMPRESSOR MOUNT LINE ROUTING FIGURE 9 905456-LFZ-A REV E 03/05/14, 56 FORD PICK UP INSTRUCTIONS PG 12 OF 19...
-
Page 13: Evaporator Bracket Installation
1956 F-100 FORD TRUCK w/ H/C/D EVAPORATOR INSTALLATION (CONTINUED) COWL VENT FLANGE TEMPLATE FROM PAGE 17. FIGURE 10 #8 x 1/2” SCREWS EVAPORATOR BRACKET FIGURE 11 905456-LFZ-A REV E 03/05/14, 56 FORD PICK UP INSTRUCTIONS PG 13 OF 19... -
Page 14: Firewall
1956 F-100 FORD TRUCK w/ H/C/D FIREWALL O.E.M. HOLE BLOWER BRACKET 1/4"-20 x 1/2" BOLT 10/32 x 1/2" MACHINE SCREW W/NUT 10/32 x 1/2" MACHINE PRE-DRILL SCREW 3/16” HOLES W/NUT 5/8” HEATER 5/8” HEATER HOSE (RETURN LINE) HOSE (SUPPLY LINE) DRAIN ELBOW #10 A/C... - Page 15 1956 F-100 FORD TRUCK w/ H/C/D COLDER CLOCKWISE ROTARY TYPE THERMOSTAT THIS STICKER LOCATED EVAPORATOR CAPILLARY ON TOP SIDE OF WARMER COUNTERCLOCKWISE TUBE EVAPORATOR CASE EVAPORATOR COIL INSERT THERMOSTAT SLIDE TYPE THERMOSTAT CAPILLARY TUBE THRU THIS HOLE. ENTIRE THICKNESS OF CAPILLARY EVAPORATOR COIL.
-
Page 16: Wiring Diagram
1956 F-100 FORD TRUCK w/ H/C/D WIRING DIAGRAM - GEN II HEAT/COOL/DEFROST YELLOW (REQUIRED) COMPRESSOR SAFETY SWITCH BINARY TYPE BLUE CLUTCH ORANGE BLACK BLACK MODE SPEED SWITCH SWITCH THERMOSTAT ORANGE YELLOW BLUE POWER RELAY ORANGE PURPLE WHITE WHITE WHITE HIGH BLOWER GROUND BLOWER... - Page 17 1956 F-100 FORD TRUCK w/ H/C/D DRIVER SIDE CORE SUPPORT TEMPLATE BOLT PLACE ON DRIVER’S SIDE OF CORE SUPPORT AS SHOWN IN FIGURE 2, PAGE 6. THIS TEMPLATE IS FOR DRIVER’S SIDE COMPRESSOR MOUNTED VEHICLES ONLY! TEMPLATE #1 BOLT FIGURE 13 FIGURE 12 FIGURE 14 905456-LFZ-A REV E 03/05/14, 56 FORD PICK UP INSTRUCTIONS PG 17 OF 19...
- Page 19 1956 F-100 FORD TRUCK w/ H/C/D PASSENGER SIDE CORE SUPPORT TEMPLATE BOLT PLACE ON PASSENGER SIDE OF CORE SUPPORT AS SHOWN IN FIGURE 2, PAGE 6. THIS TEMPLATE IS FOR DRIVER’S SIDE COMPRESSOR MOUNTED VEHICLES ONLY! TEMPLATE #2 BOLT FIGURE 15 905456-LFZ-A REV E 03/05/14, 56 FORD PICK UP INSTRUCTIONS PG 18 OF 19...
-
Page 22: Evaporator Kit Packing List
1956 F-100 FORD TRUCK w/ H/C/D 1956 FORD F-100 EVAPORATOR KIT EVAPORATOR KIT PACKING LIST 75456-LFZ-A QTY. PART No. DESCRIPTION 55288-VUE-A EN II EVAP . SUB CASE 79756-LFN ACCESSORY KIT CHECKED BY: PACKED BY: DATE: EVAP. SUB CASE 55288-VUE-A ACCESSORY KIT...
