  • Page 1 User Manual DSA-3020...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 4 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
  • Page 5 Power Adaptor Accessary List TV tuner WiFi module USA power cord European power cord UK power cord Power Code Option 1700001524 Power cord, 180cm, 180D, US/UL 170203183C Power cord, 183cm, 180D, EU 170203180A Power cord, 180cm, 180D, UK DSA-3020 User Manual...
  • Page 6 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 7 Anweisung des Herstellers. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC- 704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. DSA-3020 User Manual...
  • Page 8 Don't touch any components on the CPU card or other cards while the PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. DSA-3020 User Manual viii...
  • Page 9: Table Of Contents

    Hardware Functionality .......7 Introduction of DSA-3020 External I/O Connectors ........8 Figure 2.1 DSA-3020 front metal face plate external I/O connec- tors................8 Figure 2.2 DSA-3020 rear metal face plate I/O connectors..8 DSA-3020 front plate external I/O connectors .......... 8 2.2.1...
  • Page 10 Jumpers and Connectors................ 14 Installing the DDR2 SDRAM Memory Module ........14 Figure 3.1 The left side of DSA-3020 ........14 Figure 3.2 The right side of DSA-3020 ........15 Figure 3.3 The top side of DSA-3020 ........15 Figure 3.4 The bottom side of DSA-3020 ........16 Installing the 2.5"...
  • Page 11: Chapter 1 Overview

    Chapter Overview...
  • Page 12: Introduction

    IP/Ethernet networks. Built on an x86 platform and XP Embedded OS, it is easy for application development. The compact -size design and the standard mounting bracket of DSA-3020 means it can be easily mounted behind signage display devices.
  • Page 13: Display Compatibility

    Dimension: 170 x 110.6 x 32 mm Weight: 0.8 kg (1.76 lb) 1.2.13 Watchdog timer Output: Interrupt, system reset Interval: Programmable 1 ~ 255 sec. 1.2.14 Certification Electromagnetic: CE, FCC Safety: UL, CB, CCC Environmental protection: RoHS, WEEE DSA-3020 User Manual...
  • Page 14: Features

    Compact size for easy installation & mounting Fanless design for better reliability Supports Intel® Silverthorne XL processor Supports both landscape and portrait mode of display and dual display Supports Windows XPe & Linux Watchdog timer 1.4 System Architecture DSA-3020 User Manual...
  • Page 15: Layout

    1.5 Layout Figure 1.1 DSA-3020 Top View Figure 1.2 DSA-3020 Rear View DSA-3020 User Manual...
  • Page 16 DSA-3020 User Manual...
  • Page 17: Chapter 2 Hardware Functionality

    Chapter Hardware Functionality...
  • Page 18: Introduction Of Dsa-3020 External I/O Connectors

    Figure 2.3 DSA-3020 power button 2.2.2 LED Indicators There are two LEDs on the DSA-3020 front face plate for indicating system status: PWR LED is for power status and flashes in green color; and HDD LED is for hard disk and compact flash disk status, which flashes in a red color.
  • Page 19: Dvi Connector

    2.2.3 DVI Connector Figure 2.5 DVI Connector The DSA-3020 can support DVI-D output. The pin definition for the video connector and video cable follows: Table 2.1: DVI VIdeo Connector PIN NO# Signal PIN NO# Signal TMDS2- TMDS2+ DDCCLK DDCDAT TMDS1-...
  • Page 20: Rs232

    No Connection 2.2.7 USB Connector The DSA-3020 provides 2 connectors for USB interface, which gives complete Plug & Play and hot swapping for up to 127 external devices. The USB interface complies with USB UHCI, Rev. 2.0. The USB interface can be disabled in the system BIOS setup.
  • Page 21: Connect The Power

    The main power should be estab- lished after you press the power button! Warning! Only use the power adapter packaged with the DSA-3020. Using a dif- ferent power adapter could damage the device.
  • Page 22 DSA-3020 User Manual...
  • Page 23: Chapter 3 Hardware Installation And Upgrade

    Chapter Hardware Installation and Upgrade This chapter introduces how to initialize the DSA-3020. Sections include: Installing the DDR SDRAM Mem- ory Module Inserting a Compact Flash Card Installing the 2.5°± Hard Disk Drive (HDD) Connecting Power...
  • Page 24: Jumpers And Connectors

    3.1 Jumpers and Connectors The DSA-3020 Embedded Video System consists of a PC-based computer that is housed in a aluminum top cover, and a metal bottom case with accessible bottom cover and front with rear metal face plate. The HDD, SDRAM, are accessible by removing the top cover.
  • Page 25 Figure 3.2 The right side of DSA-3020 Remove the top cover. Figure 3.3 The top side of DSA-3020 DSA-3020 User Manual...
  • Page 26: Installing The 2.5" Hard Disk Drive (Hdd)

    3.3 Installing the 2.5" Hard Disk Drive (HDD) You can attach one enhanced Integrated Device Electronics (IDE) hard disk drive to the DSA-3020’s internal controller which uses a local bus interface. The advanced IDE controller supports faster data transfer. Figure 3.5 Installing the 2.5" Hard Disk Drive (HDD) Fix your HDD on the rim to the HDD mounting top cover using the 4 screws found in accessories box.
  • Page 27 PWR cable to provide the power which is needed by the PATA-to- SATA adapter board. Make sure there’s a good tight connection between the flat cable and the hard disc drive. Screw back the bottom cover using the 4 screws. DSA-3020 User Manual...
  • Page 28 DSA-3020 User Manual...
  • Page 29: Award Bios Setup

    Chapter Award BIOS Setup...
  • Page 30: Bios Introduction

    CPUs from 386 through Pentium and AMD Geode, K7 and K8 (including multiple pro- cessor platforms), and VIA Eden C3 and C7 CPU. You can use Advantech’s utilities to select and install features to suit your designs to your customers needs.
  • Page 31: Main Menu

    Set Password Establish, change or disable password. Save & Exit Setup Save CMOS value settings to CMOS and exit BIOS setup. Exit Without Saving Abandon all CMOS value changes and exit BIOS setup. DSA-3020 User Manual...
  • Page 32: Standard Cmos Features

    The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. Extended Memory The POST of the BIOS will determine the amount of extended memory (above 1MB in CPU’s memory address map) installed in the system. DSA-3020 User Manual...
  • Page 33: Advanced Bios Features

    Select boot device priority by Floppy. – LS120 Select boot device priority by LS120. – Hard Disk Select boot device priority by Hard Disk. – CDROM Select boot device priority by CDROM. – Select boot device priority by ZIP. DSA-3020 User Manual...
  • Page 34: Advanced Chipset Features

    (Default value) MPS Version Control for OS [1.4] This item sets the operating system multiprocessor support version. APIC Mode This item allows the user to enable APIC Mode. 4.2.4 Advanced Chipset Features DSA-3020 User Manual...
  • Page 35: Integrated Peripherals

    4.2.5 Integrated Peripherals Note! This “Integrated Peripherals” option controls the configuration of the board’s chipset, includes IDE, ATA, SATA, USB, AC97, MC97 and Super IO and Sensor devices, this page changes depending on the- Chipset. IDE HDD Block Mode DSA-3020 User Manual...
  • Page 36 Intel HD Audio Controller PCI Express Port 1 DSA-3020 User Manual...
  • Page 37: Power Management Setup

    PC and system devices for improving the power man- agement. Power Management [Min Saving] This item allows the user to select system power saving mode. – Min Saving Minimum power management. Suspend Mode=1 hr. DSA-3020 User Manual...
  • Page 38 – Delay 4 Sec Press power button 4 sec. to Power off. Watch Dog Timer Function After choosing 20 sec if the system hangs on the POST screen, then the system will auto reset after 20 seconds. DSA-3020 User Manual...
  • Page 39: Pnp/Pci Configurations

    The item is designed to solve problems caused by some non-standard VGA cards. A built-in VGA system does not need this function. INT Pin 1~8 Assignment [Auto] The interrupt request (IRQ) line assigned to a device connected to the PCI inter- face on your system. DSA-3020 User Manual...
  • Page 40: Load Setup Defaults

    Setup requires a password only to enter Setup. System requires the password either to enter Setup or to boot the system. A password may be at most 8 characters long. DSA-3020 User Manual...
  • Page 41 Select Set Password again, and at the “Enter Password” prompt, don’t enter anything; just press <Enter>. At the “Confirm Password” prompt, again, don’t type in anything; just press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. DSA-3020 User Manual...
  • Page 42: Save & Exit Setup

    Type “Y” will quit the BIOS Setup Utility and save user setup value to CMOS. Type “N” will return to BIOS Setup Utility. 4.2.11 Quit Without Saving Note! Type “Y” will quit the BIOS Setup Utility without saving to CMOS. Type “N” will return to BIOS Setup Utility. DSA-3020 User Manual...
  • Page 43: Update Bios

    When the program finished, press "F1" to restart. When system restart, press "Del" to enter the BIOS setup screen and load the BIOS default setting then exit. When the program finished, the system will shutdown by itself. DSA-3020 User Manual...
  • Page 44 Push the Button to boot the system. DSA-3020 User Manual...
  • Page 45: System Setup

    Chapter System Setup This chapter details the driver installation for DSA-3020. Sections include: Installation of chipset driver Installation of graphic driver Installation of LAN driver Installation of audio driver...
  • Page 46: Introduction

    60~70% of memory bandwidth usage at any time. 5.1.1 Display type The DSA-3020 can be set only in a VBIOS Default, CRT and TV mode. The system is initially set to “VBIOS Default”. 5.2 Driver Installation 5.2.1 Installation of a licensed Windows OS...
  • Page 47: Install The Audio Driver

    5.2.6 Install the Wireless module driver (only optional Wireless model) Find the wireless module driver from CD at the directory of DSA-3020 Utility CD: \ Please follow and pay attention to the installation instructions which appear on your screen, and complete the wireless module driver installation.
  • Page 48 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2009...
