- Page 1 DSA-2130SAE Full-HD Network digital signage media player User’s Manual Published July 2009 © 2009 Advantech...
-
Page 4: Table Of Contents
Contents Introduction 1.1. Hardware features 1.2. Software Features 1.3. Package Contents 1.4. Front Panel Indicator Lights 1.5. Rear I/O Connections 1.6. Installation provisions Configuring the DSA-2130 Media Player 2.1. System Connections 2.2. Attach a USB keyboard to the DSA-2130 2.3. Connect the DSA-2130 to your network 2.4. -
Page 5: Introduction
1. Introduction This document describes the hardware and software operations of the DSA-2130 digital signage media players, system set up, and frequently asked questions. 1.1. Hardware features The DSA-2130 Media Player is a Full-HD 1080p high definition digital signage player featuring industrial grade mechanical design and versatile open-standard SMIL programmability. -
Page 6: Package Contents
1.3. Package Contents DSA-2130 Player Unit AC Adapter and Cord Mounting Plate (x2) Software CD Screw (x4, not shown) Ethernet cable RCA to 1/8” mini-jack 1/8” to 1/8” mini-jack Quick Start Guide audio adapter audio cable INCLUDED: A USB keyboard is required for system setup 1.4. -
Page 7: Installation Provisions
1.6. Installation provisions The DSA-2130 is supplied with a pair of mounting plates for physical installation. 1. Attach the mounting plates to the bottom side of the player with 2 screws (supplied) on each side. Supplied Mounting Plates (x2) 2. The player with the mounting plates attached can be mounted using 4 screws (not supplied) at 76mm X 228mm (2.99”... -
Page 8: Configuring The Dsa-2130 Media Player
2. Configuring the DSA-2130 Media Player 2.1. System Connections Attach a video cable (either VGA or HDMI) to your monitor. When using the VGA connection, your monitor should support XGA (1024x768) resolution or greater. For audio output, you will also need to connect a stereo RCA cable from the DSA-2130 to your monitor. When using an HDMI connection, audio is sent along with video over the HDMI cable, so no additional cables are required. -
Page 9: Attach A Usb Keyboard To The Dsa-2130
enter the menu system. 2.2. Attach a USB keyboard to the DSA-2130 You must attach a USB keyboard to the DSA-2130 to configure the media player. It takes approximately 30 seconds for the following menu to be displayed: Navigating the menus Navigate the menus using arrow keys, space bar, enter key, and numeral keys on your USB keyboard. -
Page 10: Video Output Settings
2) Static – Manually Assign Network IP Address Highlight “Networking setting” and press “Enter” on the keyboard to select. Highlight “Static IP” below, press “Space bar” on the keyboard to fill in the star (*) at the Static IP brackets, and press “Enter” on the keyboard to select. -
Page 11: Clock And Calendar Settings
2.5. Clock and Calendar Settings Set the correct time zone, time, and date. Daylight Saving (DST) rules can be configured in Set time zone. 2.6. Additional Settings The menu offers other settings shown in the expanded menu view on the next pages. -
Page 13: Factory Reset Button
2.7. Factory Reset Button The S/W RESET button located at the back of the media player can be used to restore factory settings. Use the button to restore default settings or reset an unstable player state. Performing a factory reset Warning: This procedure will restore all menu settings to factory default and also format the internal storage to factory conditions (all contents removed). -
Page 14: Content Management With Manager Express
3. Content Management with Manager Express Please see Manager Express 2.0 User’s Manual for content management operation. -
Page 15: Working With Smil
4. Working with SMIL The DSA-2130 uses open communications protocols for extremely flexible content presentation and playback control. SMIL-compliance means predictable results across multiple devices, and SMIL’s non-proprietary nature means that your investments are never obsolete. 4.1. Introduction Using SMIL (pronounced “smile”), the language created by W3C for multimedia communications, the DSA-2130 understands the language “spoken”... -
Page 16: Technical Data
5. Technical Data 5.1. Specifications DSA-2130 Video format support POPAI Screen Media Standards S6 (MPEG-1 SIF, 3Mbps CBR) S7 (MPEG-1 480p, 10Mbps CBR) S8 (MPEG-1 720p, 15Mbps CBR) S9 (MPEG-2 480p, 6Mbps CBR) S10 (MPEG-2 720p, 12Mbps CBR) S11 (MPEG-4 AVC, 480p, 6Mbps CBR) S12 (MPEG-4 AVC, 720p, 10Mbps CBR) E4 (VC-1/WMV9, MP@ML, 720p) E5 (VC-1/WMV9, MP@HL, 1080p) -
Page 17: Mechanical Drawings
8.3 X 6 X 1.7 (inches) (excluding projections) Weight 1.14kg 2.5lbs Safety UL-approved AC adapters Certifications CE/FCC RoHS Warranty One-year limited parts & labor *typical usage when playing 1080P full resolution video 5.2. Mechanical Drawings Drawing shown with included mounting plate accessory, used for attaching the player via 4 screws with 76mm X 228mm (2.99”... -
Page 18: Appendix: Faq
6. Appendix: FAQ Why install .NET framework 3.5SP1 on my PC? The latest Microsoft .NET 3.5 SP1 offers improved performance and bug fixes to Manager Express. A copy of the installer is provided on the CD. What is the maximum file size for a single video file? The maximum video file size for the DSA-2130 Media Player is 2GB. - Page 19 bit rates using the free and open source Handbrake tool at http://handbrake.fr/. Once you have found the right output settings for size and quality, save them in Handbrake profiles for future use. Then you can easily recompress any unplayable files you encounter in the future. The media playback looks different on a PC compared to the media player’s screen.
