- Page 1 DS-081 Ultra Slim Digital Signage Player...
- Page 2 The documentation and the software included with this product are copyrighted 2017 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
- Page 3 CHRONTEL is a trademark of Chrontel Inc. All other product names or trademarks are properties of their respective owners. For more information about this and other Advantech products, please visit our web-site at: http://www.advantech.com/ For technical support and service, please visit our support website at: http://support.advantech.com.tw/support/...
- Page 4 Product Warranty (24 months) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
-
Page 5: Declaration Of Conformity
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. DS-081 Series User Manual... -
Page 6: Technical Support And Assistance
Technical Support and Assistance Visit the Advantech website at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: ... -
Page 7: Safety Instructions
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS. The sound pressure level at the operator's position according to IEC 704-1:1982 is no more DS-081 Series User Manual... - Page 8 RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. DS-081 Series User Manual...
-
Page 9: Packing List
Packing List Before installation, please ensure the following items have been shipped: 1 x DS-081 series player 1 x Driver/Utility Disk 1 x China RoHS Sheet 1 x Simplified Chinese User manual 1 x Traditional Chinese User manual ... - Page 10 DS-081 Series Part Number: DS-081GB-U2A1E DS-081GF-U2A1E DS-081GB-U3A1E DS-081GF-U3A1E DS-081GB-U4A1E DS-081GB-U4A1E DS081GB1701-T DS081GB1801-T DS081GB1901-T DS081GB2001-T DS081GB2101-T DS081GB1702-T DS081GB1802-T DS081GB1902-T DS081GB2002-T DS081GB2102-T DS081GB1703-T DS081GB1803-T DS081GB1903-T DS081GB2003-T DS081GB2103-T DS081GB1704-T DS081GB1804-T DS081GB1904-T DS081GB2004-T DS081GB2104-T DS081GB1705-T DS081GB1805-T DS081GB1905-T DS081GB2005-T DS081GB2105-T DS081GB1706-T DS081GB1806-T DS081GB1906-T DS081GB2006-T DS081GB2106-T...
-
Page 11: General Introduction
Chapter General Introduction This chapter gives background information on DS-081 series DS-081 Series User Manual... -
Page 12: Product Features
Core™ i5/i3 processors for UHD video playback performance. DS-081 series is powered by Intel DS-081 series is a media player that delivers advanced graphics performance for all your signage applications. DS-081 series has dual HDMI to provide multi display outputs simultaneously. For better connectivity, it supports 2x LAN, internal 1 x Mini PCIe interface for add-on functions such as wireless network/Bluetooth fulfill different requirements. -
Page 13: Mechanical Specification
– Resolution: – 4096 x 2304 @ 24Hz Expansion – MiniPCIe：1 socket internal Mechanical Specification 1.4.1 Dimension 180 x 190 x 19mm (L x W x H) Figure1.1：Diemnsions 1.4.2 Weight 0.87 kg (1.92 lbs) DS-081 Series User Manual... -
Page 14: Power Requirements
0.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis. 1.6.5 Shock During Vibration 20 G, IEC 60068-2-27, half sine, 11 ms duration 1.6.6 Safety UL, BSMI, CCC 1.6.7 CE, FCC Class B, BSMI, CCC DS-081 Series User Manual... - Page 15 Chapter Hardware Installation This chapter introduces external IO and the installation of DS-081 series Hardware DS-081 Series User Manual...
-
Page 16: Power On/Off Button
DS-081 Series External I/O Connectors 2.2.1 Power ON/OFF Button DS-081 Series has a power ON/OFF button on the front side. Push this button to turn the system ON and OFF. It also supports a 5 second delay soft power off. Figure 2.3：Power Button 2.2.2... - Page 17 TMDS Data 2- TMDS Data 1+ TMDS Data 1 shield TMDS Data 1- TMDS Data 0+ TMDS Data 0 shield TTMDS Data 0- TMDS Clock+ TMDS Clock shield TMDS Clock- Reserved DDC/CEC Ground Hot Plug Detect DS-081 Series User Manual...
-
Page 18: Usb Connectors
2.2.5 USB Connectors DS-081 Series provides four USB interface connectors, which gives complete Plug & Play and hot swapping capability for up to 127 external devices. The USB interface is compliant with USB UHCI, Rev. 3.0. The USB interface supports Plug and Play, which enables you to connect or disconnect a device without turning off the system. - Page 19 Audio Connector Figure 2.9： DS-081 Series User Manual...
-
Page 20: Hardware Installation
Fix HDD with screws on the HDD bracket Figure 2.11：HDD Bracket Installation 2.3.3 HDD Installation Remove the top cover by loosening the fixing screws Connect HDD with on board SATA connector and then fix it with screws DS-081 Series User Manual... - Page 21 Figure 2.12：HDD Installation 2.3.4 Mini PCIe Card/Memory Module Installation Remove the bottom cover by loosening the fixing screws and then insert Mini PCIe and Memory Module into the socket. Figure 2.13：Mini PCIe Card/Memory Module Installation DS-081 Series User Manual...
- Page 22 Find 4 pcs of M3 screws to affix the mounting brackets on system bottom. (The screws and mounting brackets are both included in the system accessory box) Figure 2.15：Mounting Bracket Installation (II) Using M3-6L screws to affix system on the VESA bracket module. (Note: Screws qty varies by system.) DS-081 Series User Manual...
- Page 23 Figure 2.16：Mounting Bracket Installation (III) 2.3.6 Mounting Direction Flat View Figure 2.17：Flat View Vertical - Upright Figure 2.18: Vertical - Upright DS-081 Series User Manual...
- Page 24 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2015 DS-081 Series User Manual...
