- Page 1 User Manual USM-110 Arm® Cortex®-A17 Quad-core Processor Based Mini Digital Signage Player...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Consult the dealer or an experienced radio/TV technician for help. Technical Support and Assistance Visit the Advantech web site at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 4 Discard used batteries according to the manufacturer's instructions. Note! Notes provide optional additional information. Document Feedback To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Please send all such - in writing to: support@advan- tech.com USM-110 User Manual...
- Page 5 The sound pressure level at the operator position does not exceed 70 dB (A) in accordance with the IEC 704-1:1982. DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. USM-110 User Manual...
- Page 6 Transport: carry the unit with both hands and handle with care. Maintenance: to properly maintain and clean the surfaces, use only approved products or clean with a dry applicator. European Contact Information: Advantech Europe GmbH Kolberger Straße 7 D-40599 Düsseldorf, Germany Tel: 49-211-97477350 Fax: 49-211-97477300...
-
Page 7: Table Of Contents
Figure 2.1 Front view of USM-211..........6 Figure 2.2 Rear view of USM-110 ..........6 Figure 2.3 IO Layout of USM-110..........6 Figure 2.4 IO Layout of USM-110 Delight Version ...... 6 Installation Procedures................7 2.2.1 Connecting the Power Cord............7 2.2.2... - Page 8 USM-110 User Manual viii...
-
Page 9: Chapter 1 Overview
Chapter Overview... -
Page 10: Introduction
USM-110 is integrated with Advantech’s Wise-Paas/ SignageCMS digital sig- nage management software, which allows users to layout, schedule, and dispatch signage contents to the USM-110 digital signage player over the Internet, enabling remote delivery of diverse high-resolution multimedia. 1.2 Specification 1.2.1 General Specifications... -
Page 11: Environmental Specifications
Relative humidity: 10 ~ 90% @ 40 °C (non-condensing) Shock: 10 G peak acceleration (11 ms duration) Vibration: 5 ~ 500 Hz 0.5 Grms, random Certification: CCC, CE, UL, FCC, CB, BSMI 1.3 Appearance diagram Unit:mm USM-110 User Manual... - Page 12 USM-110 User Manual...
-
Page 13: Chapter 2 Installation Instruction
Chapter Installation Instruction... -
Page 14: Quick Tour Of The Device
Line Out DC In RJ45 Antenna Antenna RS232/422/485 Figure 2.3 IO Layout of USM-110 Wi Indicator Reset Power Indicator HDMI2.0 SD Slot Antenna USB2.0 Antenna DC In RJ45 LineOut Antenna Figure 2.4 IO Layout of USM-110 Delight Version USM-110 User Manual... -
Page 15: Installation Procedures
YouTube: https://youtu.be/c_yWG_WvkmQ Youku:http://v.youku.com/v_show/ id_XMzgyMTY4NDE4MA==.html?spm=a2h3j.8428770.3416059.1 2.3.1 Device Installation USM-110 supports diverse mount options as shown below. Module Assembly (for VESA, pole, and DIN rail mounting) Step 1.Pull out the two side wings (A) at the back of the device (Figure 1). - Page 16 2.Attach the device to the mount bracket following the “Module Assembly” steps outlined above. Pole Mount Installation Step 1.Affix the mount bracket to the pole using cable ties (Figure 5). Step 2.Attach the device to the mount bracket following the “Module Assembly” steps outlined above. USM-110 User Manual...
-
Page 17: Installing The Expanded Module
1.Place the device onto a flat metal surface, using the two magnets on the side wings to hold it in place (Figure 7). 2.4 Installing the Expanded Module Step 1.Unscrew and take down the orange back cover. USM-110 User Manual... - Page 18 Step 2.Unscrew and take down the bracket. Step 3.Install the Wi-Fi or 4G module onto the M.2 or miniPCIe slot respectively as the red circle figure. Step 4.Insert antenna cable into module as illustrated in the figure. USM-110 User Manual...
- Page 19 Insert antenna cable here Insert antenna cable here Fixed screw Fixed screw 4G Module MiniPCIe Slot M.2 slot Wi-Fi Module Step 5.Remove two rubbers that cover the antenna holes, next install the antenna cable here. USM-110 User Manual...
- Page 20 Step 6.Screw the antenna on the antenna cable Step 7.Fix the bracket and orange back cover USM-110 User Manual...
-
Page 21: Chapter 3 Operation System Update/Upgrade
Chapter Operation System Update/Upgrade... -
Page 22: Usb Upgrade Option (Recommended)
The latest OS has been pre-installed in the USM-110. If users need update the OS, the steps necessary to install an operating system on the device are explained below. There are two options to update the OS. Note! Some distributors and system integrators may have pre-installed system software before shipping the computer. -
Page 23: Sd Card Upgrade Option
3.2 SD card upgrade option Preparation: One PC or notebook based on Windows system One Micro SD card Get the tool of “AdroidTool” package from Advantech website Get the tool of “SD_Firmware_Tool._v1.46” tool from Advantech website 3.2.1 Create upgrade file Update.img Step 1.Extract the files“boot.img”?“kernel.img”?“misc.img”, “recovery.img”,... - Page 24 Step 1 Step 2 Step 3 Step 4 Step 6.After creation, select “Yes” on one pop-up dialog window. 7.Automatically complete, click the “ 确定 ” button Step USM-110 User Manual...
-
Page 25: Usm-110 Device Image Update
Take out the SD card from PC or Notebook, and insert the SD card into the SD slot of USM-110 then power on. And follow the step shown on system then take out the SD card and restart the USM-110. - Page 26 USM-110 User Manual...
-
Page 27: Chapter 4 System Setup
Chapter System Setup... -
Page 28: How To Install Apk
4.1 How to install APK Step 1.Start USM-110, click “Apkinstaller” on the menu pages. Step 2.Step2. Choose the Install Step 3. Choose the storage disc where your APK is. Step 4.Click the APK that you want to install. Step 5.Click “Install”... - Page 29 Step 6.Click “Done” to complete the APK installation. USM-110 User Manual...
-
Page 30: How To Uninstall One Apk
4.2 How to uninstall one APK Step 1.Choose “Setting” function Step 2.Click “APPs”, and choose the APK you want to remove from the APP list. Step 3.Click “Uninstall” button for the process of uninstallation. USM-110 User Manual... -
Page 31: System Setting
Step 4.Select “OK” to run uninstalling. 4.3 System Setting 4.3.1 Screen Rotate Step 1.Choose “Setting” function Step 2.Choose “Display” USM-110 User Manual... - Page 32 Step 3.Select “Screen rotation” Step 4.Choose the angle you want to rotate. USM-110 User Manual...
-
Page 33: Wise-Paas/Signagecms Application
Chapter WISE-PaaS/ SignageCMS Application... -
Page 34: Wise-Paas/Signagecms Software Arthitecture
Each server support to connect unlimited clients, it will depend on the network condition. For more detailed information about how to use SignageCMS, please download the SignageCMS user manual from below link. https://support.ushop-plus.com/download USM-110 User Manual... -
Page 35: Signagecms Client And Server Connection Setting
ID] is ticked. Note! The value of [Client ID] or [Custom ID] are needed in [Client device] function of server system Step 3.Please check if the “Silent Installation” is ticked that can enable the auto upgrade. USM-110 User Manual... - Page 36 ID] of client system. Option2. If the [Use custom ID] is not selected, please input the [Client ID] of client system Step 7.Click [Save & Exit] Step 8.Back to [Client Device], check the [status] column of the device list, the green indicator say you finish adding one device. USM-110 User Manual...
-
Page 37: Wise-Paas/Signagecms Client Screen Setting
USM device supports to show independent content in two screens, it can not split one video or image in two screens. Additionally, using two screens with extension model, please set the screen which connects the HDMI1 source on the left or top, please refer to the following illustration. USM-110 User Manual... - Page 38 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...
