DSA-2130 Digital Signage Player
Quick Start Guide

Box Contents

Media Player Unit
Ethernet Cable
USB Keyboard required
The Manager Express CD contains:
Manager Express Installer (for Windows PC)
•
DSA-2130 User's Manual (PDF)
•
Quick Start Guide (PDF)
•
AC Power Adapter
12V DC output
Audio Adapter Cable:
RCA to 3.5 mm
A USB keyboard is required to access the media player's
built-in menu configuration for making system changes.
Player Mounting
Bracket
Audio Cable:
3.5 mm to 3.5 mm
Manager Express CD
Quick Start Guide
(this guide)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSA-2130 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech DSA-2130

Summary of Contents for Advantech DSA-2130

  • Page 1: Quick Start Guide

    DSA-2130 Digital Signage Player Quick Start Guide Box Contents Media Player Unit AC Power Adapter Player Mounting Manager Express CD 12V DC output Bracket Ethernet Cable Audio Cable: Quick Start Guide Audio Adapter Cable: 3.5 mm to 3.5 mm RCA to 3.5 mm (this guide) A USB keyboard is required to access the media player’s...
  • Page 2 When using the VGA connection, your monitor should support XGA (1024x768) resolution or greater. For audio output, you will also need to connect a stereo RCA cable from the DSA-2130 to your monitor. When using an HDMI connection, audio is sent along with video over the HDMI cable, so no additional cables are required.
  • Page 3 Attach the AC power adapter to power on the unit. The green power indicator will immediately light up, followed by the amber status indicator in approximately 15 seconds. Shortly afterwards, the following progress bar will be displayed on your monitor: ~ 90 seconds Player boot process takes approximately 90 seconds to complete.
  • Page 4 Playing media files using a network connection For detailed instructions on how to set up your player and management software system on a network, please refer to the DSA-2130 Media Player User’s Manual in the Manager Express CD. Scala Network Ready The DSA-2130 can be connected to a Scala Content Manager network via an optional Scala software license.
