weBoost Office 200 Install Manual

weBoost Installed | Office 200
Discard After Installation
2-Way
Splitter
coax cable
see chart below for recommended
cable lengths for Inside Antenna

RECOMMENDED CABLE LENGTHS

BASED ON OUTSIDE SIGNAL
STRENGTH
OUTSIDE
SIGNAL STRENGTH
-90 dBm
-80 dBm
-70 or higher
Note: Minimum coax cable length for
Outside Antenna is 20 feet.

LIGHT PATTERNS

Use the color LCD to verify each band is
green.
If there is a band that is not green, tap it to
see troubleshooting guidance
LCD Touchscreen Off
If the Signal Booster's light is off, verify your
power supply has power.
Inside Antennas

BOOSTED SIGNAL

Typical Signal Results
-105 to -90 Good
dBm
-91 to -85 Better
dBm
-86 to -65 Excellent
dBm
The Outside Antenna must be at least 60 feet horizontal or 25 feet
vertical distance from Inside Antenna for best performance
MAX CABLE LENGTH
100 feet
125 feet
150 feet
SIGNAL RECEIVED
-120 to -105
-104 to -90
-89 to -80
see chart below for recommended
cable lengths for Outside Antenna
Booster
to power

TROUBLESHOOTING

If you are happy with the coverage, these
light issues don't have to be resolved. The
carrier's band has not been affected.
Fixing Any Red Light Issues
1. Verify the Inside Antenna is at least
24" from the Booster.
2. Tighten all cable connections (be
sure to handtighten only, do NOT use
tools). You may want to undo and redo
the connection completely. Unplug
and re-plug in power supply.
3. Increase the distance (horizontally or
vertically) between the Outside and
Inside antenna. Un-plug and re-plug in
power supply.

Outside Antenna

Typical Signal Results
Poor
dBm
Fair
dBm
Good
dBm
coax cable
