3.3 Technical data

3.3.1 Product identification data

Product name
Article number
Serial number
Date of manufacture
Table 4: Product identification data

3.3.2 Type plate

The type plate is located on the right side of the product housing

3.3.3 Water connections

The UV-unit is designed for operation with the following water connections
Description
Plug-in hose nozzle 9/10 mm
Plug-in hose nozzle 12/13 mm
Plug-in angle 90 °
Water connection adapter 12 mm
Water connection adapter 15 mm
Table 5: Water connections
Compatible connection adapters can be found in the chapter Spare parts and accessories p.(57), at specialist
accessory dealers and on the manufacturer's homepage www.wm-aquatec.de.

3.3.4 Electrical connections

The UV-unit is designed for operation with the following electrical connections
Description
Wire-tap connectors
(wire cross-section 0.5
Solder wire connector
(for operation with flow sensor)
Table 6: Electrical connections
...1.5 mm )
2 2 2
- 39 -
UV-C LED Water disinfection unit
BLUVC0812
see type plate or service card
see type plate or service card
Included in the scope of delivery
yes
yes
yes
no
no
Included in the scope of delivery
yes
no
