Aspley -
Assembly Instructions
Dimensions
Width - 101cm
Depth - 202.5cm
Height - 102cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, ca ll th e
Bed
3FT
- Please keep for future reference
498/9622
490/9664
Customer Helpline:03456400800
Issue 1 - 20/11/15
Advertisement
Related Manuals for Argos Aspley 498/9622
Summary of Contents for Argos Aspley 498/9622
- Page 1 Aspley - Assembly Instructions - Please keep for future reference 498/9622 490/9664 Dimensions Width - 101cm Depth - 202.5cm Height - 102cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, ca ll th e Customer Helpline:03456400800 Issue 1 - 20/11/15...
- Page 2 Safety and Care Advice Important –Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not from natural timber; you may recommend the components and tools listed on pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Headboard (100.0 x 98.9cm) Footboard (34.0 x 98.9cm) Side rail x 2 (190.0 x 11.0cm) Slats x 12 (91.0 x 7.0cm) Headboard top rail ( 101.0 x 6.8cm) Footboard top rail ( 101.0 x 6.8cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel x 10 4 x 35mm Screw x 24 Headless bolt 1/4 x 75mm x 4...
- Page 5 Assembly Instructions Step1 Insert dowels into the side rails Step2 Insert wooden dowels into headboard and footboard as . headboard and footboard as shown.
- Page 6 Assembly Instructions Step3 Fixing top rail Caution: Carefully lay the headboard top rail on a soft and clean surface to avoid damaging the produc Fix headboard top rail the headboard using bolts and allen key Step4 Fixing top rails Caution: Carefully lay the footboard top rail on a soft and...
- Page 7 Assembly Instructions Step5 Fit footboard top rail to the footboard. Insert locking nuts where shown. Use a screwdriver to turn locking nuts clockwise to lock. Step6 Screw headless bolts into footboard...
- Page 8 Assembly Instructions Step7 Assembling side rails. Important: Two people are required for an easier assembly. With help, fit one side to the headboard Insert half moon nuts as shown, then fix parts and allen key using bolts Repeat step 7 for the other Repeat step 7 for the other side rail.
- Page 9 Assembly Instructions Step9 Assembling slats Please fix the first slat at the end of the rail and work towards the middle of the bed using the spacer as shown to ensure correct spacing. Fix slats in one side first, then fix them in the other side by pushing the rail against the slats if necessary.
