- Page 1 PAN301x ® Bluetooth Low Energy Module Module Integration Guide Rev. 1.0 Wireless Connectivity...
- Page 2 PAN301x Bluetooth Module 1 About This Document Overview Characteristics • The PAN301x is a Bluetooth 5 Low Energy (LE) Typical sensitivity: -88 dBm • module based on ST’s BlueNRG-2 Bluetooth low Typical max. output power: 8 dBm • energy single mode system-on-chip. Typical current consumption: 16 mA in Tx and 9 mA in Rx mode •...
- Page 3 Panasonic Industrial Devices Europe GmbH (Panasonic) reserves the right to make changes as required at any time without notification. Please consult the most recently issued Module Integration Guide before initiating or completing a design.
- Page 4 To the maximum extent allowable by Law Panasonic assumes no liability whatsoever including without limitation, indirect, consequential, special, or incidental damages or loss, including without limitation loss of profits, loss of opportunities, business interruption, and loss of data.
-
Page 5: Table Of Contents
PAN301x Bluetooth Module 1 About This Document Table of Contents About This Document ......................... 6 Purpose and Audience........................6 Revision History ..........................6 Use of Symbols ...........................6 Related Documents ........................7 Overview .............................. 8 PAN301x Module ..........................9 Block Diagrams ...........................9 Footprints ..........................10 Placement ..........................11 Reference Design .......................... -
Page 6: About This Document
PAN301x Bluetooth Module 1 About This Document 1 About This Document 1.1 Purpose and Audience This Module Integration Guide is intended to support the easy integration of the PAN301x into a product and to ensure the compliance with regulatory requirements. This guide gives an overview about the hardware design requirements by providing a reference design, which is the evaluation board of the PAN301x. -
Page 7: Related Documents
The message Failed to save your data is displayed. Enter the value Product 123. Indicates a key on the keyboard, e.g. F10 . 1.4 Related Documents 8.2 Product For related documents please refer to the Panasonic website Information. Module Integration Guide Rev. 1.0 Page 7 of 30... -
Page 8: Overview
Creating IoT Solution Modules like the PAN3011, PAN3012, and PAN3013, that clearly contribute to cutting down time-to-market in development processes in these rather fast paced times of innovation and automatization has been the clear priority for Panasonic Industry. Being based on and inspired by the ST BlueTile (STEVAL-BCN002V1B) multi-sensor development kit, customers are now able to test and evaluate their ideas easily and bring new IoT products appropriately fast and at a reduced BOM to the markets. -
Page 9: Pan301X Module
PAN301x Bluetooth Module 3 PAN301x Module 3 PAN301x Module 3.1 Block Diagrams PAN3011 PAN3012 PAN3013 PAN3013 2.6 V to 3.5 V IoT-SB â Bluetooth Low Energy (LE) Sensor Module I²C Crystal UART Accelerometer/ 32 MHz Gyroscope LSM6DSO Crystal 32.768 kHz... -
Page 10: Footprints
PAN301x Bluetooth Module 3 PAN301x Module 3.2 Footprints The dimensions are in millimeters. The outer dimensions have a tolerance of ±0.3 mm. PAN3011/PAN3012 Top View 25.00 1.50 0.25 2.00 PAN3013 Top View 31.00 1.50 0.25 2.00 Module Integration Guide Rev. 1.0 Page 10 of 30... -
Page 11: Placement
PAN301x Bluetooth Module 3 PAN301x Module 3.3 Placement Antenna “Keep out Area” Do not place any ground plane under the marked restricted antenna area in any layer! This would be affecting the performance of the chip antenna in a critical manner. - Page 12 PAN301x Bluetooth Module 3 PAN301x Module Time of Flight (ToF) Sensor (PAN3013) It is recommended to use a cover window with the dimension of maximum 12 mm × 8.5 mm. It provides physical protection for the sensor, including protection for the dust ingress and it provides optical filtering for the sensor.
-
Page 13: Reference Design
PAN301x Bluetooth Module 4 Reference Design 4 Reference Design The reference design, shown in the block diagram below, gives an example of how to use the PAN301x, to get connection over FTDI UART and J-Link SWD. 4.1 Block Diagram Battery CR2032 Volt-Reg. -
Page 14: Schematic
PAN301x Bluetooth Module 4 Reference Design 4.2 Schematic Module Integration Guide Rev. 1.0 Page 14 of 30... -
Page 15: Building Blocks
PAN301x Bluetooth Module 4 Reference Design 4.3 Building Blocks JTAG SWD Program m ing and debugging Level shift er User RGB LED FTDI USB t o UART conversion User But t on Breakout pins access t o all sensor m odule pins Reset but t on Boot but t on Module Integration Guide Rev. -
Page 16: Breakout Pins
PAN301x Bluetooth Module 4 Reference Design 4.4 Breakout Pins µUSB SWDI O WDCLK ( GND) I 2C_SDA I 2C_SCL DI O_6 RESET BOOT DI O_3 PDM_CLK UART_TX PDM_DATA UART_RX SWDI O DI O_0 SWDCLK DI O_14 ATEST I NT_3X ADC1 I NT_COM NRST... -
Page 17: Configuration Settings
PAN301x Bluetooth Module 4 Reference Design 4.5 Configuration Settings Operation over X1 (Micro-USB) Operation over P9 (TTL-232R-3V3 cable) Operation over P7 → Set jumper at P10 Operation over CR2032 battery (without due to UART control (USB or P9) UART control) Use connector P9 only with the FTDI USB to UART cable “TTL-232R-3V3”. -
Page 18: Pcb Layout
PAN301x Bluetooth Module 4 Reference Design Jumper Description Power supply of LED D5 (operation control) Disconnect this jumper to reduce the supply current when using a CR2032 coin cell. Option to break the power supply to the sensor module. Jumper can be removed for current measurements at P7 or for direct power supply to the sensor module. -
Page 19: Software: Steval-Bcn002V1B Development Kit
PAN301x Bluetooth Module 5 Software: STEVAL-BCN002V1B Development Kit 5 Software: STEVAL-BCN002V1B Development Kit The PAN301x sensor modules are based on and inspired by the ST BlueTile (STEVAL-BCN002V1B) multi-sensor development kit. Testing and evaluation of the software can be done with this development kit. Due to the similar circuit, the software will also work on the PAN301x sensor modules. -
Page 20: Regulatory And Certification Information
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Panasonic Industrial Devices Europe GmbH may void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 21 The OEM must ensure that FCC labelling requirements are met. This includes a clearly visible label on the outside of the OEM enclosure specifying the appropriate Panasonic FCC identifier for this product as well as the FCC Notice above. The FCC identifier is FCC ID: T7V301X.
- Page 22 PAN301x Bluetooth Module 6 Regulatory and Certification Information 6.2.6 RF Exposure To comply with FCC RF Exposure requirements, the OEM must ensure that 6.2.5 Approved only antennas from the Approved Antenna List are installed Antenna List. The preceding statement must be included as a “CAUTION” statement in manuals for products operating with the approved antennas in the previous table to alert users on FCC RF Exposure compliance.
-
Page 23: Innovation, Science, And Economic Development (Ised) For Canada
PAN301x Bluetooth Module 6 Regulatory and Certification Information 2.6 RF exposure considerations Mobile application, the end customer has to assure that the device has a distance of more than 20 cm from the human body under all circumstances. 2.7 Antennas ... - Page 24 PAN301x Bluetooth Module 6 Regulatory and Certification Information 6.2.5 Approved This device has been designed to operate with the antennas listed in Antenna List, having a maximum gain of 1.6 dBi. Antennas not included in this list or having a gain greater than 1.6 dBi are strictly prohibited for use with this device.
- Page 25 PAN301x Bluetooth Module 6 Regulatory and Certification Information Le client final doit s'assurer que l'appareil se trouve en toutes circonstances à une distance de plus de 15 mm du corps humain. Si le client final envisage une application nécessitant d'utiliser le PAN3011, PAN3012, PAN3013 à...
- Page 26 The OEM must ensure that IC labelling requirements are met. This includes a clearly visible label on the outside of the OEM enclosure specifying the appropriate Panasonic IC identifier for this product as well as the IC Notice above. The IC identifier is IC: 216Q-301X.
-
Page 27: European Conformity According To Red (2014/53/Eu)
PAN301x Bluetooth Module 6 Regulatory and Certification Information 6.4 European Conformity According to RED (2014/53/EU) All modules described in this Module Integration Guide comply with the standards according to the following LVD (2014/35/EU), EMC-D (2014/30/EU) together with RED (2014/53/EU) articles. Standards •... -
Page 28: Bluetooth
PAN301x Bluetooth Module 6 Regulatory and Certification Information 6.5 Bluetooth For Bluetooth end products which integrate the PAN301x the OEM needs to apply for an own end product listing (EPL) at the Bluetooth SIG. If the PAN301x is used on more than one OEM product, costs can be saved by applying for a family EPL. -
Page 29: Restricted Use
Panasonic customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Panasonic Industrial Devices Europe GmbH for any damages resulting. -
Page 30: Contact Details
PAN301x Bluetooth Module 8 Contact Details 8 Contact Details 8.1 Contact Us Please contact your local Panasonic Sales office for details on additional product options and services: For Panasonic Sales assistance in the EU, visit https://eu.industrial.panasonic.com/about-us/contact-us Email: wireless@eu.panasonic.com For Panasonic Sales assistance in North America, visit the Panasonic website “Sales &...
